Self made 5GHz antenna

Is it possible to make homemade 5,6GHz antenna? I need it only for 100m link.

Reply to
Jan Werbiñski
Loading thread data ...

Yes, it is.

Reply to
mattjohnson2005

any link?

Reply to
Jan Werbiñski

5.8GHz antennas for 802.11a are produced commercially.
formatting link
is one vendor.

Is this for a PC/laptop, or the access point, or both? Does an existing link work at all at this length? Is it clear line of site between two windows, outdoors, brick buildings, trees?

The D-Link AirPremier AG DWL-AG530 PCI card comes with an external antenna.

There is no reason that you couldn't build your own, except that tolerances are tight, but for this distance, that doesn't matter. A cantenna should be about 50mm in diameter, 150-200mm long.

If you have an existing access point, you might just put a reflector on it, like

formatting link
EZ-12, although the + point for the antenna should be half as far away from the reflector.

Reply to
dold
