Broadband Max service on a cisco 837

Can you post the results of a 'sh dsl int atm0'?

Chris.

Hi chris here it is show dsl int atm0 ATU-R (DS) ATU-C (US) Modem Status: Showtime (DMTDSL_SHOWTIME) DSL Mode: ITU G.992.1 (G.DMT) ITU STD NUM: 0x01 0x01 Vendor ID: 'ALCB' 'ALCB' Vendor Specific: 0x0000 0x0000 Vendor Country: 0x00 0x0F Capacity Used: 81% 89% Noise Margin: 12.0 dB 10.0 dB Output Power: 20.0 dBm 12.0 dBm Attenuation: 18.5 dB 11.0 dB Defect Status: None None Last Fail Code: None Selftest Result: 0x00 Subfunction: 0x15 Interrupts: 1286 (2 spurious) Activations: 2 Init FW: embedded Operartion FW: embedded SW Version: 3.9.220 FW Version: 0x1A04 Interleave Fast Interleave Fast Speed (kbps): 7616 0

832 0 Reed-Solomon EC: 2 0 17 0 CRC Errors: 0 0 8 0 Header Errors: 0 0 5 0 Bit Errors: 0 0 BER Valid sec: 0 0 BER Invalid sec: 0 0 LOM Monitoring : Disabled DMT Bits Per Bin 00: 0 0 0 0 0 0 0 6 7 8 9 A B B B C 10: C C C C C B B B B A 9 8 8 8 0 0 20: 0 0 0 0 0 0 3 4 4 5 6 7 7 8 9 9 30: 9 A A A A A B B B B B B B B B B 40: 0 B B B B B B B B B B B B B B C 50: C C C C C C C C C C C C C C C 2 60: C B C B B B B B B B B B B B B B 70: B B B B B B B B B B B B B B B B 80: B B B B B A B B B B B B A B B A 90: A A A A A A A A A A A A A A A A A0: A A A A A A A A A A A A A A A A B0: A A A A A A A A A A 9 A A 9 A 9 C0: 9 9 9 A 9 9 9 9 9 9 9 9 9 9 9 9 D0: 9 9 9 9 9 9 9 9 9 9 8 9 8 9 8 8 E0: 8 8 8 8 8 8 8 8 8 8 8 8 8 7 7 7 F0: 7 7 7 6 5 4 4 3 2 2 0 0 0 0 0 0 Training log buffer capability is not enabled yet.

Hi Jon,

You may wish to investigate Cisco ADSL configuration wizards:

Hope this helps.

Brad Reese on Cisco Network World Magazine Cisco Subnet

Well, you've trained up at a good speed and there's no errors. You shouldn't be having any issues at all.

Chris.

That looks OK compared with what I see.

It says that the downstream rate is 7616 kbps and the upstream is 800k.

There have been a fer Error Correction events and maybe a few Error Corerction failures (CRC and Header errors)

The issue does not appear to be with the raw ADSL speed negotiated.

Maybe the router is running out of CPU?

The easiest thing is if you post the whole config.

Remove passwords, user names, change real ip addresses (in such a way that the config can be understood).

Also change the config as fiollows

int dialer x ! whatever you use load-interval 30

re-run the test and post

sh proc cpu ! first line only sh int dialer x When the download test has been running for a bit but has not yet stopped.

Check that you are not getting packet fragmentation

sh ip traffic

On Mar 4, 6:43 pm, snipped-for-privacy@hotmail.co.uk wrote:

here is the config will test cpu bandwidth this afternoon Current configuration : 1545 bytes ! version 12.3 no service pad service timestamps debug uptime service timestamps log uptime no service password-encryption ! hostname ! enable secret 5 enable password ! no aaa new-model ip subnet-zero no ip domain lookup ! ! ip audit notify log ip audit po max-events 100 no ftp-server write-enable ! ! ! ! ! ! ! interface Ethernet0 ip address (external Wan ip address) 255.255.255.248 hold-queue 100 out ! interface ATM0 bandwidth 8000 no ip address atm vc-per-vp 64 no atm ilmi-keepalive pvc 0/38 encapsulation aal5mux ppp dialer dialer pool-member 1 ! dsl operating-mode itu-dmt ! interface FastEthernet1 description connected to SonicWALL no ip address duplex auto speed auto hold-queue 100 out ! interface FastEthernet2 no ip address shutdown duplex auto speed auto ! interface FastEthernet3 no ip address shutdown duplex auto speed auto ! interface FastEthernet4 description connected to Internet no ip address duplex auto speed auto ! interface Dialer1 description connected to Internet bandwidth 8000 ip unnumbered Ethernet0 encapsulation ppp dialer pool 1 no cdp enable ppp chap hostname ppp chap password 0 ! ip classless ip route 0.0.0.0 0.0.0.0 Dialer1 no ip http server no ip http secure-server ! dialer-list 1 protocol ip permit ! line con 0 exec-timeout 0 0 password no modem enable stopbits 1 line aux 0 line vty 0 4 access-class 23 in exec-timeout 120 0 password login ! scheduler max-task-time 5000 ! end

That looks ideal. Could hardly be simpler. Key thing is fast switching is not disabled "no ip route cache".

Hi,

RE: int dialer1 load-interval 30

Adding this command made the speed even slower.

Results from other commands are;

sh proc cpu CPU utilization for five seconds: 22%/14%; one minute: 10%; five minutes: 6%

sh int dialer1 Dialer1 is up, line protocol is up (spoofing) Hardware is Unknown Description: connected to Internet Interface is unnumbered. Using address of Ethernet0 (195.97.201.5) MTU 1500 bytes, BW 56 Kbit, DLY 20000 usec, reliability 255/255, txload 1/255, rxload 1/255 Encapsulation PPP, loopback not set DTR is pulsed for 1 seconds on reset Interface is bound to Vi2 Last input never, output never, output hang never Last clearing of "show interface" counters 00:09:06 Input queue: 2/75/0/0 (size/max/drops/flushes); Total output drops:

0 Queueing strategy: weighted fair Output queue: 0/1000/64/0 (size/max total/threshold/drops) Conversations 0/0/16 (active/max active/max total) Reserved Conversations 0/0 (allocated/max allocated) Available Bandwidth 42 kilobits/sec 5 minute input rate 0 bits/sec, 0 packets/sec 5 minute output rate 0 bits/sec, 0 packets/sec 6619 packets input, 6194149 bytes 5882 packets output, 1168207 bytes Bound to: Virtual-Access2 is up, line protocol is up Hardware is Virtual Access interface MTU 1500 bytes, BW 56 Kbit, DLY 100000 usec, reliability 255/255, txload 72/255, rxload 114/255 Encapsulation PPP, LCP Open Open: IPCP PPPoATM vaccess, cloned from Dialer1 Bound to ATM0 VCD: 1, VPI: 0, VCI: 38, loopback not set DTR is pulsed for 5 seconds on reset Interface is bound to Di1 (Encapsulation PPP) Last input 00:00:00, output never, output hang never Last clearing of "show interface" counters 00:08:40 Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0 Queueing strategy: fifo Output queue: 0/40 (size/max) 5 minute input rate 86000 bits/sec, 10 packets/sec 5 minute output rate 16000 bits/sec, 8 packets/sec 6629 packets input, 6194295 bytes, 0 no buffer Received 0 broadcasts, 0 runts, 0 giants, 0 throttles 0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort 5892 packets output, 1169534 bytes, 0 underruns 0 output errors, 0 collisions, 0 interface resets 0 output buffer failures, 0 output buffers swapped out 0 carrier transitions

sh ip traffic. IP statistics: Rcvd: 3939 total, 119 local destination 0 format errors, 0 checksum errors, 0 bad hop count 0 unknown protocol, 0 not a gateway 0 security failures, 0 bad options, 0 with options Opts: 0 end, 0 nop, 0 basic security, 0 loose source route 0 timestamp, 0 extended security, 0 record route 0 stream ID, 0 strict source route, 0 alert, 0 cipso, 0 ump 0 other Frags: 0 reassembled, 0 timeouts, 0 couldn't reassemble 0 fragmented, 0 couldn't fragment Bcast: 36 received, 0 sent Mcast: 0 received, 0 sent Sent: 74 generated, 3805 forwarded Drop: 15 encapsulation failed, 0 unresolved, 0 no adjacency 0 no route, 0 unicast RPF, 0 forced drop

ICMP statistics: Rcvd: 0 format errors, 0 checksum errors, 0 redirects, 0 unreachable 4 echo, 0 echo reply, 0 mask requests, 0 mask replies, 0 quench 0 parameter, 0 timestamp, 0 info request, 0 other 0 irdp solicitations, 0 irdp advertisements Sent: 0 redirects, 1 unreachable, 0 echo, 4 echo reply 0 mask requests, 0 mask replies, 0 quench, 0 timestamp 0 info reply, 0 time exceeded, 0 parameter problem 0 irdp solicitations, 0 irdp advertisements

UDP statistics: Rcvd: 36 total, 0 checksum errors, 36 no port Sent: 0 total, 0 forwarded broadcasts

TCP statistics: Rcvd: 79 total, 0 checksum errors, 0 no port Sent: 70 total

PIMv2 statistics: Sent/Received Total: 0/0, 0 checksum errors, 0 format errors Registers: 0/0, Register Stops: 0/0, Hellos: 0/0 Join/Prunes: 0/0, Asserts: 0/0, grafts: 0/0 Bootstraps: 0/0, Candidate_RP_Advertisements: 0/0 State-Refresh: 0/0

IGMP statistics: Sent/Received Total: 0/0, Format errors: 0/0, Checksum errors: 0/0 Host Queries: 0/0, Host Reports: 0/0, Host Leaves: 0/0 DVMRP: 0/0, PIM: 0/0

ARP statistics: Rcvd: 1 requests, 0 replies, 0 reverse, 0 other Sent: 0 requests, 4 replies (0 proxy), 0 reverse

no ip route-cache This also made no difference.

Thanks,

Jon
