May anyone tell me what "Plus Feature Set" means? Or how to gather informations about that? It should concern about firewall feature of IOS Is it true?

In particular I would know if that feature is available on Cisco 851 because I didn't find out that model with the extensione -SEC- as for 837 and 877. Do you know whether exists an 856 model. I didn't find out any information.

Thanks, Alex.

Reply to
Loading thread data ...

In article , AM wrote: :May anyone tell me what "Plus Feature Set" means? :Or how to gather informations about that?

The Cisco Feature Navigator is good for this,

formatting link
You need a CCO login for this (but not necessarily a support contract.)

:It should concern about firewall feature of IOS :Is it true?

No, Plus is not related to Firewall.

:In particular I would know if that feature is available on Cisco 851 because I didn't find out that model with the :extensione -SEC- as for 837 and 877.

ADVANCED SECURITY is the only feature set for the 851. That includes the firewall features.

:Do you know whether exists an 856 model. I didn't find out any information.

No 856 model has been announced. (I don't have any idea whether there will be one.)

The extra features in 12.4(2)T1 IP/FW/PLUS 3DES compared to IP/FW/3DES, are:

Advanced Encryption Standard (AES) BGP BGP 4 BGP 4 Multipath Support BGP 4 Prefix Filter and In-bound Route Maps BGP 4 Soft Config BGP Conditional Route Injection BGP Cost Community Support for EIGRP MPLS VPN PE-CE BGP Hide Local-Autonomous System BGP Hybrid CLI Support BGP Increased Support of Numbered as-path Access Lists BGP Link Bandwidth BGP Multipath Load Sharing for Both eBGP and iBGP in an MPLS-VPN BGP Named Community Lists BGP Nonstop Forwarding (NSF) Awareness Support BGP Policy Accounting BGP Prefix-Based Outbound Route Filtering BGP Restart Neighbor Session After max-prefix Limit Reached BGP Route-Map Policy List Support BGP Soft Reset CEFv6/dCEFv6 - Cisco Express Forwarding Certification Authority Interoperability (CA) Class Based Traffic Policing with CLP Tagging Control Plane DSCP Support for RSVP COPS for RSVP DRP Server Agent Dynamic Multipoint VPN (DMVPN) Phase 1 EIGRP Prefix Limit Support EIGRP Support for Route Map Filtering Enhanced IGRP (EIGRP) Enhanced IGRP Stub Routing Firewall N2H2 Support Firewall Websense URL Filtering Generic Routing Encapsulation (GRE) Generic Routing Encapsulation (GRE) Tunnel Keepalive HSRP - Hot Standby Router Protocol iBGP Multipath Load Sharing IP Enhanced IGRP Route Authentication IP over IPv6 tunnels IPv6 (Internet Protocol Version 6) IPv6 Access Services: AAA Support for Cisco VSA IPv6 Attributes IPv6 Access Services: PPPoA IPv6 Access Services: PPPoE IPv6 Access Services: Prefix Pools IPv6 ACL Extensions for Mobile IPv6 IPv6 Data Link: VLANs using Cisco Inter-Switch Link (ISL) IPv6 Data Link: VLANs using IEEE 802.1Q Encapsulation IPv6 Default Router Preference IPv6 IOS Firewall FTP Application Support IPv6 MTU Path Discovery IPv6 Neighbor Discovery IPv6 Policy-Based Routing IPv6 Routing: Multiprotocol BGP Extensions for IPv6 IPv6 Routing: Multiprotocol BGP Link-local Address Peering IPv6 Routing: OSPF for IPv6 (OSPFv3) IPv6 Routing: RIP for IPv6 (RIPng) IPv6 Routing: Route Redistribution IPv6 Routing: Static Routing IPv6 Security: Secure Shell SSH support over IPv6 IPv6 Services: AAAA DNS Lookups over an IPv4 Transport IPv6 Services: Cisco Discovery Protocol (CDP) - IPv6 Address Family Support for Neighbor Information IPv6 Services: DNS Lookups over an IPv6 Transport IPv6 Services: Extended Access Control Lists IPv6 Services: Generic Prefix IPv6 Services: Standard Access Control Lists IPv6 Stateless Auto-configuration IPv6 Static Cache Entry for Neighbor Discovery IPv6 Switching: CEF/dCEF Support IPv6 Switching: CEFv6 Switched Automatic IPv4-compatible Tunnels IPv6 Switching: CEFv6 Switched Configured IPv6 over IPv4 Tunnels IPv6 Tunneling: Automatic 6to4 Tunnels IPv6 Tunneling: Automatic IPv4-compatible Tunnels IPv6 Tunneling: IPv6 over IPv4 GRE Tunnels IPv6 Tunneling: ISATAP Tunnel Support IPv6 Tunneling: Manually Configured IPv6 over IPv4 Tunnels IPv6: ICMPv6 IPv6: ICMPv6 Redirect IPv6: Neighbor Discovery Duplicate Address Detection Low Latency Queueing (LLQ) Modular QoS CLI (MQC) Three-Level Hierarchical Policer Multicast Source Discovery Protocol (MSDP) Multilink PPP NAT - Protocol Translation (NAT-PT) NAT-PT: Support for DNS ALG Network Time Protocol (NTP) Next Hop Resolution Protocol (NHRP) OSPF OSPF ABR type 3 LSA Filtering OSPF Area Transit Capability OSPF Flooding Reduction OSPF Forwarding Address Suppression in Translated Type-5 LSAs OSPF Inbound Filtering using Route Maps with a Distribute List OSPF Link State Database Overload Protection OSPF Link-local Signaling (LLS) Per Interface Basis OSPF Nonstop Forwarding Awareness OSPF Not-So-Stubby Areas (NSSA) OSPF On Demand Circuit (RFC 1793) OSPF Packet Pacing OSPF Sham-Link Support for MPLS VPN OSPF Shortest Paths First Throttling OSPF Stub Router Advertisement OSPF Support for Fast Hellos OSPF Support for Multi-VRF on CE Routers OSPF Update Packet-Pacing Configurable Timers Percentage-Based Policing and Shaping PIM Multicast Scalability PIM Version 1 PIM Version 2 Policer Enhancement - Multiple Actions Priority Queueing (PQ) QoS for Virtual Private Networks QoS Policy Propagation via Border Gateway Protocol (QPPB) RADIUS Random Early Detection (RED) RSVP - Resource Reservation Protocol RSVP Local Policy Support RSVP Message Authentication RSVP Refresh Reduction and Reliable Messaging RSVP Scalability Enhancements RSVP support for LLQ RSVP Support for RTP Header Compression RTP Header Compression Single Rate 3-Color Marker for Traffic Policing SNMP Over IPv6 Support Subnetwork Bandwidth Manager (SBM) Trimble Palisade NTP Synchronization Driver Two-Rate Policer WCCP Redirection on Inbound Interfaces WCCP Version 1 WCCP Version 2
