In article , snipped-for-privacy@gmail.com writes: | You can configure FXS ports to register to CME as SCCP endpoints | beginning in 12.4(2)T.
Yes, unfortunately, 12.4T is not available on the 3640. I'm looking at moving the voice ports to a 3660. Amusingly it looks like some of the interesting voice commands need 12.4(20)T and the 3660 seems to stop just short of that. I'm a little surprised--given that the 3600 series was "multi-service" and all--that it has taken so long for the IOS voice support to catch up that the platform became obsolete before you could do reasonably basic operations like ringing multiple extensions. :(
|
formatting link
| html#wp1010395 | | Then try configuring shared-lines for ephones representing the fxs
Yes, that would work, and I think making the FXS ports look like ephones would also allow features to be enabled. But I can't make them SCCP devices in 12.4 and I can't figure out if there is some other protocol with similar functionality.
The ultimate solution is probably to use Asterisk. My worry then is that IOS might get confused whan a forking SIP proxy sends a call that it originated back its way. It *shouldn't* but that's just the kind of thing that seems to break. I noticed that if you enable call hairpinning in 12.4 it generates all sorts of memory alignment errors as each call comes through.
Dan Lanciani ddl@danlan.*com
| hth, | ant | | On Oct 26, 11:17=A0pm, ddl@danlan.*com (Dan Lanciani) wrote: | > In article , for-s...@mail.= | com (headsetadapter.com) writes: | > | Dan, | > | | > | How your router configured? | >
| > At the moment it has an NM-HDA-4FXS with 4FXO. | >
| > |Do you use CallManager Express? | >
| > No, if I can't do this with basic dial peers I thought I'd probably | > use an external program like Asterisk. =A0CME seems a little limited in | > 12.4. =A0In particular it doesn't seem to be possible to configure FXS | > ports as ePhones. | >
| > | Basically, if you need to ring multiple phone numbers at once, you need= | to | > | create Hunt Group (ephone-hunt). You will configure one "pilot number" = | and | > | specify which list of DNs and in which order (sequential order or broad= | cast) | > | should ring. And then you configure PLAR on FXO with this pilot number. | >
| > Will that work ok with plar opx? =A0(I don't want the FXO port to pick up | > unless and until somebody answers.) Which version of CME supports broadca= | st | > hunt groups? =A0From what I could tell this was a feature of "full" CCM | > only. =A0Even the CME in 12.4T doesn't seem to have it. | >
| > Any thoughts on enabling features on FXS ports or picking up ringing FXO | > ports? | >
| > =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 Dan Lanci= | ani | > =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 =A0 ddl@danla= | n.*com | >
| > | > How can I direct an incoming call on an FXO port to simultaneously ri= | ng | > | > one or more FXS ports and one or more VOIP destinations, connecting t= | he | > | > first that answers? =A0Dial-peers seem to be sequential. =A0I can ima= | gine | > | > going through an external forking SIP proxy that loops back to the | > | > router, but that seems messy. | > | >
| > | > Is it possible to enable features (e.g., call waiting) on FXS ports w= | ith | > | > IOS 12.4? =A0The examples I've seen seem to make the FXS ports look l= | ike | > | > ephones using commands that apparently require 12.4T. | > | >
| > | > Is it possible to pick up a ringing FXO line by dialing an extension | > | > that points to that port? =A0I can set up a dial-peer pointing to an | > | > FXO port and dialing its number connects me to dial tone on the FXO | > | > port if the line is idle. =A0But if the line is ringing I get a busy. | > | > (If I time it just right to dial the extension as the call is coming | > | > in but before it actually starts to ring I can connect. =A0Basically = | I'd | > | > like to tell IOS to not try to prevent glare in this case.)
