Need help to install a AC power in a router 3620

I am about to replace a DC power supply unit with a AC one in a 3620. I order the AC unit from

formatting link
The AC unit has 3 sets of sockets: 1 big and 2 small ones. They are all female. There is only one big male socket on the mother board so I have no problem with this. However, there are 2 small male sockets on the mother board. I am confused to choose which female socket from the AC power supply unit to plug into which male socket on the mother board.

The 2 sets both have the same cables colors. And there is no label or any indication on the cables or the sockets to differentiate the 2.

I am tempting just to plug them it. I have 50% chance to get it right :-) I have a feeling that if I make a mistake, it won't cook the 3620. I don't know much about Cisco gear to I guess I'd better to ask first.

Any help would be very appreciate. ZP.

Reply to
Zoong Pham
Loading thread data ...

You may wish to investigate Cisco Power Supply Documentation:

formatting link
Sincerely,

Brad Reese BradReese.Com - Cisco Repair

formatting link
Hendersonville Road, Suite 17 Asheville, North Carolina USA 28803 USA & Canada: 877-549-2680 International: 828-277-7272 Fax: 775-254-3558 AIM: R2MGrant Website:
formatting link

Reply to
www.BradReese.Com
