Will IR Illuminator work with any CCD Camera?

snipped-for-privacy@yahoo.com wrote in news:1167535711.108842.63610 @n51g2000cwc.googlegroups.com:

You need to make sure the cameras do not have an IR cutoff filter. Being color, they most likely do. But check to be sure. If they don't have one, then they will work. If they do have the filter, you will need a LOT more IR to make it work.

Brian

Unless you have a real need for obscurity, there's a much simpler (and usually less expensive) approach to covert CCTV. Speco makes a standard motion detector light with two flood lamps that come on for a couple of minutes any time someone walks by after dark. Most people are so accustomed to seeing these lights that they don't give them a second thought.

What the subject won't know is that there's a camera mounted inside the motion detector. One advantage of this approach is that you'll get a much better, more detailed image with white (well, close to white) light than with IR. Another advantage is that when most people trigger those lights the first thing they do is look up directly at them. This will give you an excellent chance at recording the person's face.

I might be a little biased in favor of Speco since I sell it online. However, I've used their cameras with good results on several of my own installations.

Simplest way to find out if a particular camera is IR sensitve: look at the lcd or evf while someone holds a TV remote and punches a few buttons for you - see if you can see the signal.

Thanks for the answers, that was quick. Looks like a had better not assume the camera will work with the illuminator, and had better check it.

Just to elaborate...I'm trying to keep a sleek look on the house with no wall mounted lamps etc. I don't even want a small IR dome camera sitting under the soffit. I'd like to use bullit cameras and just have the tip sticking through a small hole in the soffit. Otherwise I'd use wall mounted motion lamps, or purpose-built IR daynight dome cameras mounted under the soffit.

You may find it difficult to aim the camera preciselt where you want it unless the hole is over sized. The other issue will be the illuminator. Anything powerful enough to give good video from more than a few feet away will require a fiarly large IR array. One of our vendors, Extreme CCTV, has a very informative website. They make a wide assortment of cameras and IR illuminators. Their hardware is about as good as it gets in this industry. Prices are not cheap. Here's their URL. I think you'll find it an interesting browse. There are sections of the site dedicated to IR illuminators, cameras and combination camera/illuminators. Being mostly a commercial / industrial CCTV maker, many of their products will your aesthetic requirements. If the range is satisfactory, you might want to consider their WZ series day/night cameras.

I mentioned Speco in an earlier post. In addition to "covert" cameras, they make a number of bullet style cameras. One which you might find interesting is the HT-INTB2. This is an "intensifier" type of camera, designed for extremely low light operation. URL follows:

These are just a couple of examples. There are lots to look at. Let me know if I can be of assistance.

What hath ray wrought:

How is the remote's infrared light changed (modulated?) into visible light?

[FuT sci.electronics.basics]

Hrvoje Bratanic AKA Shuckey AKA Crtowat AKA No-Fun

This is not a good test. The IR from a remote control is very bright. It can be seen by cameras with an IR filter installed.

Just check with the camera manufacturer that there us no IR filter present.

Please visit my web site at

B+W surveillance cameras generally see very well with infrared. I use Sony SSC M383's and am pretty impressed with their IR performance.

The one thing you will find is that many people who sell IR illuminators tend to flat-out lie about their performance (think used car salesmen). For example, they will tell you that illuminator X has a range of 50 feet. When you plug it in, you find the useable range is less than 15 feet.

Before buying, get *written* performance info so that you are on the same page as the salesman. If they say the range is 50 feet, force them to tell you exactly what the exact performance is at that range.

My best performer is a forced air-cooled 500 watt flood with an opaque IR filter.

One source of confusion is that the camera manufacturers' literature often cites as range the maximum distance for "usable video." The problem with this is usable video equates to "you can see something happening out there." If your only purpose is to know that something is happening but you don't care what it is or whjo is doing it, that would be ok.

Sunlight also works well. :^)

If so, one could aim the remote at the wall or a sheet of paper, instead of directly at the camera. If the camera sees a bright spot on the wall, then it can see IR.

Just tried this with my own camera, which I'm pretty sure has an IR filter. It sees a bright flash when a remote is pointed directly at it, but nothing shows up when both the camera and remote are pointed at a sheet of paper.

That also works, unless you get some sales yahoo that doesn't know anyth> How is the remote's infrared light changed (modulated?) into visible light?

It isn't. The camera either can or cannot detect the IR from the remote. If it can, a person will know it by looking at the camera's LCD monitor.

Mark

you've read posts from rlb too?

cites as range the maximum distance for "usable video."

happening out there." If your only purpose is to know that

would be ok.

As I understand it, the reason for including an IR filter is that the focal planes for IR and visible light are different enough that there's a noticeable blur in the image if both sources are present, as in sunlight.

I don't know to what extent this can be corrected by an achromatic lens as is used to correct for chromatic aberation on quality visible light cameras.

There is another basic reason to filter out IR. What color do you assign to its signal? It represents illumination you can't see, so no matter what you do with it, it distorts the visible representation of the scene. The more expensive the camera (assuming it is designed to capture visible images), the more likely that it will include a short pass filter to block light that silicon can see that you cannot. Cheap cameras that have none usually show the IR as green, for some reason. Possibly an artifact of the non-ideal bandpass characteristic of the narrow band green filter.

Good point!!!

cites as range the maximum distance for "usable video."

happening out there." If your only purpose is to know that

that would be ok.

In the days when manual focus was the norm, any decent lens had markings on it for IR focus as well as visible light. There wasn't a huge difference usually but it was there. At the time the filter wasn't an issue--most film didn't have much IR sensitivity--if you wanted IR you had to use IR film. With digital cameras it's not that simple because you can't change the sensor--the manufacturer either has to put in the IR filter and remove most of the IR capability from the camera or he has to leave it off and field the complaints from the people who don't understand that using an IR blocking filter on their lenses is the price they have to pay for an IR-capable camera.

I don't know the best solution to that problem or even if there is one--a built-in filter that can be easily field-removed would be one option but that has its own issues.

Don't know which group "rlb" refers to. No, it's just my general experience that if you want technical details that aren't listed in a product's published spec sheet, they often aren't known by either the first person (receptionist) or second person (sales or other "customer interface" person) whom you talk to on the phone.

Maybe I'm wrong in this case, and decent sales people know which of their cameras have IR filters and which don't.

Mark

That is just Don joining with the dishonest "professionals" from Alt.Security.Alarms to trash Robert Bass because they don't like him. You will find a constant bashing of him from people with aliases that don't post useful information.

Charles Sullivan wrote: ...

There is a more serious problem, and that is the fact that silicon is transmissive in the near infrared (it is opaque in the visible). That means that the NIR radiation falling on one pixel will travel through the detector material and light up adjacent pixels, degrading the MTF. There is nothing a lens can do to fix that, you just have to filter it out.

Brian Ancient and Modern Optics

Probably not al all.
