Hello,
I hope someone can help as this one has been killing me. I have been using a 2620 and WIC1-ADSL on my line for many years no problems. Connecting a new Cisco 827 and I can't get a thing. It doesn't seem to pick up the line.
I have upgraded to a few of the latest IOS's, tried different line cords including a crossover in case I got a bad cord. The line cord that works on the 2620/WIC-1 ADSL should be the same for the 827 as far as I can see on the Cisco site. Either way I've crossed 2&3 & 4&5 on a new cable too still no result.
I seem to think I am still stuck on layer 1 and would really like to know if someone has seen this before. I have attached some outputs below to see what is going on.
Thanks in advance, Greg
Router# show version System image file is "flash:c820-y6-mz.123-15.bin"
CISCO C827 (MPC855T) processor (revision 0x501) with 48128K/1024K bytes of memory. Processor board ID JAD043608TY (2304846820), with hardware revision
6711 CPU rev number 5 Bridging software. 1 Ethernet/IEEE 802.3 interface(s) 1 ATM network interface(s) 128K bytes of non-volatile configuration memory. 8192K bytes of processor board System flash (Read/Write) 2048K bytes of processor board Web flash (Read/Write)Configuration register is 0x2102
Configuration ============= =============
version 12.3 no service pad service timestamps debug datetime msec service timestamps log datetime msec no service password-encryption ! hostname Router ! boot-start-marker boot-end-marker ! no aaa new-model ip subnet-zero ip name-server 213.208.106.212 ip name-server 213.208.106.213 ! ip cef ! interface Ethernet0 ip address 192.168.0.254 255.255.255.0 ip nat inside hold-queue 100 out ! interface ATM0 no ip address no atm ilmi-keepalive dsl operating-mode auto pvc 0/38 encapsulation aal5mux ppp dialer dialer pool-member 1 ! interface Dialer0 ip address negotiated ip accounting output-packets ip nat outside encapsulation ppp dialer pool 1 dialer idle-timeout 0 dialer persistent dialer-group 1 ppp authentication chap callin ppp chap hostname snipped-for-privacy@gotadsl.co.uk ppp chap password 0 xxxxxxxxxxx ! ip nat inside source list 1 interface Dialer0 overload ip classless ip route 0.0.0.0 0.0.0.0 Dialer0 ip http server ! dialer-list 1 protocol ip permit ! line con 0 stopbits 1 line vty 0 4 access-class 2 in login local ! scheduler max-task-time 5000 end
Router#show controllers atm 0 ============================= =============================
PQUICC_SAR (with Alcatel ADSL Module) unit 0 idb at 0x80CEC744, driver data stru cture at 0x80D243C4 SCC Registers: General [GSMR]=0x1F80:0x00000000, Protocol-specific [PSMR]=0x0 Events [SCCE]=0x0000, Mask [SCCM]=0x0000, Status [SCCS]=0x0000 Transmit on Demand [TODR]=0x0, Data Sync [DSR]=0x7E7E Interrupt Registers: Config [CICR]=0x00368481, Pending [CIPR]=0x00004000 Mask [CIMR]=0x40241010, In-srv [CISR]=0x00000000 Command register [CR]=0x600 Port A [PADIR]=0xACF8, [PAPAR]=0x0303 [PAODR]=0x0000, [PADAT]=0x2E6B Port B [PBDIR]=0x02B130, [PBPAR]=0x0110C0 [PBODR]=0x000000, [PBDAT]=0x0225D9 Port C [PCDIR]=0x0002, [PCPAR]=0x0000 [PCSO]=0x0031, [PCDAT]=0x0CC2, [PCINT]=0x0000 Port D [PDDIR]=0x000000, [PDPAR]=0x00FFFF [PDDAT]=0x000FFF SI [SIMODE]=0x00001000, [SIGMR]=0x00, [SISTR]=0x00 [SICR]=0x00000025 BRGC [BRGC2]=0x0001027E, [BRGC3]=0x00000000
SCC SAR PARAMETER RAM (at 0xFF003F00) Rx BD Base [RBASE]=0x80D24760, Fn Code [RFCR]=0x18, Status [SRSTATE]=0xD0 Tx BD Base [TBASE]=0x80D25160, Fn Code [TFCR]=0x10, Status [STSTATE]=0x80 Exception Q [INTBASE]=0x80D29FD8, [INTPTR]=0x80D29FD8, [INT_CNT]=1, [INT_ICNT]=1
Connection Tbl Base [CTBASE]=0xA40 Max Rx Buff Len [MRBLR]=0 Rx State [RSTATE]=0x18000000 Tx State [TSTATE]=0x10000000 Tx Q base [TQBASE]=0xB00, [TQAPTR]=0xB00, [TQTPTR]=0xB00, [TCNT]=0, [T_PTR]=0x0 Rx Values [SMRBLR]=1536, [RCNT]=0, [R_PTR]=0x0 Idle cell header uses ATM FORUM format
AAL2 Parameter RAM (0xFF003FC0): RISC_Timer_Enable=0, Scratch1 Base=0x0, Scratch2 Base=0x0 TXWAIT_BASE=0x0, TXWAIT_PTR=0x0, TXWAIT_WIDTH=0x0, TXWAIT_LAST=0x0 TPD Base=0x0, RPD Base=0x0, CRC_TABLE_PTR=0x0
CONNECTION TABLE Default connection table [0xFF002A40] for connid=0, real conn id=0 RCT[0]: rx.status=0x4, rx.imask=0xF, rbd_base=0x0, rbd_ptr=0x0 TCT[0]: tx.status=0x8, tx.cellhdr=0x0, tbd_base=0x0 tbd_ptr=0x0
Default connection table [0x80D29C80] for connid=1, real conn id=257 RCT[1]: rx.status=0x4, rx.imask=0x0, rbd_base=0x30, rbd_ptr=0x30 TCT[1]: tx.status=0x0, tx.cellhdr=0x0, tbd_base=0x30 tbd_ptr=0x30
Default connection table [0x80D29CC0] for connid=2, real conn id=258 RCT[2]: rx.status=0x4, rx.imask=0x0, rbd_base=0x60, rbd_ptr=0x60 TCT[2]: tx.status=0x0, tx.cellhdr=0x0, tbd_base=0x60 tbd_ptr=0x60
ADDRESS MATCHING TABLE Address Compression Table Used Num of first_level_entries=32 Num of second_level_entries=1024
Num Interrupt Q overflows = 0, Interrupt Queue: ........... ........... ........... ........... ........... ........... ........... ........... ........... ........... ........... ........... ... Num valid int Q events = 0 First Int Q entry = 0x80D29FD8, expt_read_p = 0x80D29FD8
GENERAL ATM STATISTICS: Num invalid cells recv = 0 Last invalid cell recv = 0x0 Scheduling of idle cells = 0 Traffic Shaping disabled = 0
CONFIGURED VCS ARE:
---------- VC(0) ---------- TX and RX VC for OAM cells and default RX VC vc_type = 0 TX RING CONFIG: conn_id = 0, srvc_type = 2, credit = 1, bs = 1, peak_int_delay = 0, no traffic shape = 0, TxBD RING STATS: Num of packets written to TX ring = 0 Num TX interrupts received = 0 Num frames not added to ring = 0, CBR cell TX = 0, tx_cell_lastcnt = 0 Empty CBR cell slot = 0, numCellsToSend = 0 RxBD RING STATS: Now in busy state = 0, Num RX busy int = 0 Total num RX interrupts received = 0 Num RX interrupts received for data = 0 Num RX packets dropped because there is no RX buffer = 0 Num HEC errors (HEC) = 0, Num aborts (ABT) = 0 Num length errors (LN) = 0, Num CRC errors (CR) = 0 Num frames received with CLP bit set (CLP) = 0 Num frames received with PTI congestion bit set (CNG) = 0 BDs in RX ring: Shadow start BD = 0x80D3AF40, Shadow end BD = 0x80D3B0A8 nextRxBd: Shadow = 0x80D3AF40, Real = 0x80D24760
1 Real rbd=0x80D24760 Status=0x9000 Buf=0x2F36480 Len=1528 N 2 Real rbd=0x80D2476C Status=0x9000 Buf=0x2F35DB0 Len=1528 3 Real rbd=0x80D24778 Status=0x9000 Buf=0x2F356F0 Len=1528 4 Real rbd=0x80D24784 Status=0x9000 Buf=0x2F35020 Len=1528 5 Real rbd=0x80D24790 Status=0x9000 Buf=0x2F34960 Len=1528 6 Real rbd=0x80D2479C Status=0x9000 Buf=0x2F34290 Len=1528 7 Real rbd=0x80D247A8 Status=0x9000 Buf=0x2F33BD0 Len=1528 8 Real rbd=0x80D247B4 Status=0x9000 Buf=0x2F33500 Len=1528 9 Real rbd=0x80D247C0 Status=0x9000 Buf=0x2F32E40 Len=1528 10 Real rbd=0x80D247CC Status=0x9000 Buf=0x2F32770 Len=1528 11 Real rbd=0x80D247D8 Status=0x9000 Buf=0x2F320B0 Len=1528 12 Real rbd=0x80D247E4 Status=0x9000 Buf=0x2F319E0 Len=1528 13 Real rbd=0x80D247F0 Status=0x9000 Buf=0x2F31320 Len=1528 14 Real rbd=0x80D247FC Status=0x9000 Buf=0x2F30C50 Len=1528 15 Real rbd=0x80D24808 Status=0x9000 Buf=0x2F30590 Len=1528 16 Real rbd=0x80D24814 Status=0xB000 Buf=0x2F2FEC0 Len=1528 BDs in TX ring: Shadow start BD = 0x80D3AD94, Shadow end BD = 0x80D3AEFC nextTxBd: Shadow = 0x80D3AD94, Real = 0x80D25160 usedTxBd: Shadow = 0x80D3AD94, Real = 0x80D25160 1 Real tbd=0x80D25160 Status=0x0 Buf=0x2F662B0 Len=52 NU 2 Real tbd=0x80D2516C Status=0x0 Buf=0x2F66310 Len=52 3 Real tbd=0x80D25178 Status=0x0 Buf=0x2F66370 Len=52 4 Real tbd=0x80D25184 Status=0x0 Buf=0x2F663D0 Len=52 5 Real tbd=0x80D25190 Status=0x0 Buf=0x2F66430 Len=52 6 Real tbd=0x80D2519C Status=0x0 Buf=0x2F66490 Len=52 7 Real tbd=0x80D251A8 Status=0x0 Buf=0x2F664F0 Len=52 8 Real tbd=0x80D251B4 Status=0x0 Buf=0x2F66550 Len=52 9 Real tbd=0x80D251C0 Status=0x0 Buf=0x2F665B0 Len=52 10 Real tbd=0x80D251CC Status=0x0 Buf=0x2F66610 Len=52 11 Real tbd=0x80D251D8 Status=0x0 Buf=0x2F66670 Len=52 12 Real tbd=0x80D251E4 Status=0x0 Buf=0x2F666D0 Len=52 13 Real tbd=0x80D251F0 Status=0x0 Buf=0x2F66730 Len=52 14 Real tbd=0x80D251FC Status=0x0 Buf=0x2F66790 Len=52 15 Real tbd=0x80D25208 Status=0x0 Buf=0x2F667F0 Len=52 16 Real tbd=0x80D25214 Status=0x2000 Buf=0x2F66850 Len=52---------- VC(1) ---------- VPI = 0, VCI = 38,
Line has not yet been activated. No information available.
Router# show interface atm 0 ============================ ============================
ATM0 is down, line protocol is down Hardware is PQUICC_SAR (with Alcatel ADSL Module) MTU 1500 bytes, sub MTU 1500, BW 800 Kbit, DLY 80 usec, reliability 0/255, txload 1/255, rxload 1/255 Encapsulation ATM, loopback not set Encapsulation(s): AAL5 AAL2, PVC mode 10 maximum active VCs, 1024 VCs per VP, 0 current VCCs VC Auto Creation Disabled. VC idle disconnect time: 300 seconds Last input never, output never, output hang never Last clearing of "show interface" counters never Input queue: 0/75/0/0 (size/max/drops/flushes); Total output drops: 0 Queueing strategy: Per VC Queueing 5 minute input rate 0 bits/sec, 0 packets/sec 5 minute output rate 0 bits/sec, 0 packets/sec 0 packets input, 0 bytes, 0 no buffer Received 0 broadcasts, 0 runts, 0 giants, 0 throttles 0 input errors, 0 CRC, 0 frame, 0 overrun, 0 ignored, 0 abort 0 packets output, 0 bytes, 0 underruns 0 output errors, 0 collisions, 2 interface resets 0 output buffer failures, 0 output buffers swapped out
Router#DEBUG ATM EVENTS ======================= =======================
*Mar 1 00:24:10.739: DSL: Could not establish connection *Mar 1 00:24:10.739: DSL: Sent command 0x4 *Mar 1 00:24:10.739: DSL: Send ADSL_OPEN command. *Mar 1 00:24:10.739: DSL: Using subfunction 0x2 *Mar 1 00:24:10.739: DSL: Using subfunction 0x2 *Mar 1 00:24:10.739: DSL: Sent command 0x3 *Mar 1 00:24:10.767: DSL: Received response: 0x25 *Mar 1 00:24:10.771: DSL: Unexpected response 0x25 *Mar 1 00:24:10.771: DSL: Send ADSL_OPEN command. *Mar 1 00:24:10.771: DSL: Using subfunction 0x2 *Mar 1 00:24:10.771: DSL: Using subfunction 0x2 *Mar 1 00:24:10.771: DSL: Sent command 0x3 *Mar 1 00:24:13.271: DSL: 1: Modem state = 0x8 *Mar 1 00:24:15.775: DSL: 2: Modem state = 0x8 *Mar 1 00:24:18.275: DSL: 3: Modem state = 0x8 *Mar 1 00:24:20.775: DSL: 4: Modem state = 0x8 *Mar 1 00:24:23.279: DSL: 5: Modem state = 0x8 *Mar 1 00:24:25.779: DSL: 6: Modem state = 0x8 *Mar 1 00:24:28.279: DSL: 7: Modem state = 0x8 *Mar 1 00:24:30.779: DSL: 8: Modem state = 0x8 *Mar 1 00:24:33.279: DSL: 9: Modem state = 0x8 *Mar 1 00:24:35.779: DSL: 10: Modem state = 0x8 *Mar 1 00:24:38.279: DSL: 11: Modem state = 0x8 *Mar 1 00:24:40.779: DSL: 12: Modem state = 0x8 *Mar 1 00:24:43.279: DSL: 13: Modem state = 0x8 *Mar 1 00:24:45.779: DSL: 14: Modem state = 0x8 *Mar 1 00:24:48.279: DSL: 15: Modem state = 0x8 *Mar 1 00:24:50.779: DSL: 16: Modem state = 0x8 *Mar 1 00:24:53.279: DSL: 17: Modem state = 0x8 *Mar 1 00:24:55.779: DSL: 18: Modem state = 0x8 *Mar 1 00:24:58.279: DSL: 19: Modem state = 0x8 *Mar 1 00:25:00.779: DSL: 20: Modem state = 0x8 *Mar 1 00:25:03.279: DSL: Could not establish connection *Mar 1 00:25:03.279: DSL: Sent command 0x4 *Mar 1 00:25:03.279: DSL: Send ADSL_OPEN command. *Mar 1 00:25:03.279: DSL: Using subfunction 0x2 *Mar 1 00:25:03.279: DSL: Using subfunction 0x2 *Mar 1 00:25:03.279: DSL: Sent command 0x3 *Mar 1 00:25:03.315: DSL: Received response: 0x25 *Mar 1 00:25:03.315: DSL: Unexpected response 0x25 *Mar 1 00:25:03.315: DSL: Send ADSL_OPEN command. *Mar 1 00:25:03.315: DSL: Using subfunction 0x2 *Mar 1 00:25:03.315: DSL: Using subfunction 0x2 *Mar 1 00:25:03.315: DSL: Sent command 0x3 *Mar 1 00:25:05.819: DSL: 1: Modem state = 0x8 *Mar 1 00:25:08.319: DSL: 2: Modem state = 0x8 *Mar 1 00:25:10.819: DSL: 3: Modem state = 0x8 *Mar 1 00:25:13.319: DSL: 4: Modem state = 0x8 *Mar 1 00:25:15.819: DSL: 5: Modem state = 0x8
