Hello all, I have 2 WAN Connections.
1=Broadband connection with static IP (172.23.14.2) 2=T-1 connection with static IP (172.23.14.1) I want all traffic to default to the Broadband connection (172.23.14.2) but I need a few IPs to route over to the T-1. The IPs I need to route to the T-1 are... 128.1.0.3 172.16.0.154 192.168.192.37How & where to I enter this information? I only have the GUI interface to work with. In the PDM I have the following setup and it is not working... Under the Configuration - Host/Networks tab I've added an Outside Interface named Blah with the following specs.
Basic Info IP = 128.1.0.3 Mask = 255.255.255.255 Int = outside Name = Blah
Routing Checked Define Static Route Gateway IP = 172.23.14.1 Metric = 2
I have the same setup for the other 2 IPs as well(with different names). I've applied the command and saved the router config and it still doesn't route. FYI, I changed the Interface to also be Inside just in case and it did not change any of the final results.
Thank you in advance for your assistance!!!!!
Here is my config... FYI, I've replaced passwords with zzzzz & our outside Interface with x.x.x.x
Result of firewall command: "sh run"
: Saved : PIX Version 6.3(5) interface ethernet0 auto interface ethernet1 100full nameif ethernet0 outside security0 nameif ethernet1 inside security100 enable password zzzzz encrypted passwd zzzzz encrypted hostname pixfirewall domain-name ciscopix.com clock timezone EST -5 clock summer-time EDT recurring fixup protocol dns maximum-length 512 fixup protocol ftp 21 fixup protocol h323 h225 1720 fixup protocol h323 ras 1718-1719 fixup protocol http 80 fixup protocol rsh 514 fixup protocol rtsp 554 fixup protocol sip 5060 fixup protocol sip udp 5060 fixup protocol skinny 2000 fixup protocol smtp 25 fixup protocol sqlnet 1521 fixup protocol tftp 69 names name 128.1.0.3 blah access-list inside_outbound_nat0_acl permit ip any 172.23.14.128
255.255.255.192 access-list inside_outbound_nat0_acl permit ip any 172.23.14.160 255.255.255.224 access-list outside_access_in permit tcp any interface outside eq 3389 pager lines 24 mtu outside 1500 mtu inside 1500 ip address outside x.x.x.x 255.255.255.252 ip address inside 172.23.14.2 255.255.255.0 ip audit info action alarm ip audit attack action alarm ip local pool vpnpool 172.23.14.151-172.23.14.160 pdm location 172.23.14.0 255.255.255.0 inside pdm location 65.165.202.144 255.255.255.248 outside pdm location 204.118.126.3 255.255.255.255 outside pdm location 204.181.35.98 255.255.255.255 outside pdm location 204.249.224.128 255.255.255.192 outside pdm location 24.106.195.64 255.255.255.192 outside pdm location 24.106.200.64 255.255.255.248 outside pdm location 192.168.1.0 255.255.255.0 inside pdm location 172.23.14.5 255.255.255.255 inside pdm location 172.23.14.160 255.255.255.224 outside pdm location 172.23.14.128 255.255.255.192 outside pdm location blah 255.255.255.255 outside pdm logging informational 100 pdm history enable arp timeout 14400 global (outside) 1 interface nat (inside) 0 access-list inside_outbound_nat0_acl nat (inside) 1 0.0.0.0 0.0.0.0 0 0 static (inside,outside) tcp interface 3389 172.23.14.5 3389 netmask 255.255.255.255 0 0 access-group outside_access_in in interface outside route outside 0.0.0.0 0.0.0.0 24.38.95.117 1 route outside Meditech 255.255.255.255 172.23.14.1 2 timeout xlate 0:05:00 timeout conn 1:00:00 half-closed 0:10:00 udp 0:02:00 rpc 0:10:00 h225 1:00:00 timeout h323 0:05:00 mgcp 0:05:00 sip 0:30:00 sip_media 0:02:00 timeout sip-disconnect 0:02:00 sip-invite 0:03:00 timeout uauth 0:05:00 absolute aaa-server TACACS+ protocol tacacs+ aaa-server TACACS+ max-failed-attempts 3 aaa-server TACACS+ deadtime 10 aaa-server RADIUS protocol radius aaa-server RADIUS max-failed-attempts 3 aaa-server RADIUS deadtime 10 aaa-server LOCAL protocol local http server enable http 204.181.35.98 255.255.255.255 outside http 24.106.195.64 255.255.255.192 outside http 24.106.200.64 255.255.255.248 outside http 192.168.1.0 255.255.255.0 inside http 172.23.14.0 255.255.255.0 inside no snmp-server location no snmp-server contact snmp-server community public no snmp-server enable traps floodguard enable sysopt connection permit-ipsec sysopt connection permit-pptp crypto ipsec transform-set ESP-3DES-SHA esp-3des esp-sha-hmac crypto ipsec transform-set ESP-3DES-MD5 esp-3des esp-md5-hmac isakmp enable outside isakmp enable inside telnet 172.23.14.0 255.255.255.0 inside telnet 192.168.1.0 255.255.255.0 inside telnet timeout 5 ssh timeout 5 console timeout 0 vpdn group PPTP-VPDN-GROUP accept dialin pptp vpdn group PPTP-VPDN-GROUP ppp authentication mschap vpdn group PPTP-VPDN-GROUP ppp encryption mppe auto required vpdn group PPTP-VPDN-GROUP client configuration address local vpnpool vpdn group PPTP-VPDN-GROUP pptp echo 60 vpdn group PPTP-VPDN-GROUP client authentication local vpdn username administrator password ********* vpdn username helpdesk password ********* vpdn username mblackburn password ********* vpdn username bseiss password ********* vpdn username rviola password ********* vpdn username moc2 password ********* vpdn enable outside vpdn enable inside dhcpd lease 3600 dhcpd ping_timeout 750 dhcpd auto_config outside terminal width 80 Cryptochecksum:zzzzz : end
