I need code for nating in ppp multilink environment

I need help from someone to set nating in multilink environment

My router internal ip address is : 192.168.1.2 My router external ip address is : 125.117.1.177 My router multilink ip address is : 125.117.16.58 IP that i want to appear outside for internet browsing: 125.117.1.178

All i need is correct code to set nat on this router so that i can browse internet from 192.168.1.X series machines. I need this badly......

Below is the code on my Cisco 2610 router

************************ Current configuration : 1605 bytes ! version 12.3 service timestamps debug datetime msec service timestamps log datetime msec no service password-encryption ! hostname ggsairtel ! boot-start-marker boot-end-marker ! ! memory-size iomem 10 no aaa new-model ip subnet-zero ip cef ! ! ip domain name ggsindia.com ip name-server 202.56.250.5 ip name-server 202.56.230.5 ! ! username cisco privilege 15 secret 5 $1$IQtx$IuJCcgVGertyW1jfoGHTK0 ! ! ! interface Multilink1 ip address 125.117.16.58 255.255.255.252 ppp multilink ppp multilink group 1 ! interface Ethernet0/0 description *****Local marskarthik Network***** ip address 192.168.1.2 255.255.255.0 secondary ip address 125.117.1.177 255.255.255.240 ip nat inside no ip route-cache cef no ip route-cache no ip mroute-cache full-duplex ! interface Serial0/0 bandwidth 2048 no ip address encapsulation ppp no ip route-cache cef no ip route-cache no ip mroute-cache no fair-queue ppp multilink ppp multilink group 1 ! interface Serial0/1 bandwidth 2048 no ip address encapsulation ppp no ip route-cache cef no ip route-cache no ip mroute-cache no fair-queue ppp multilink ppp multilink group 1 ! ! ip http server ip classless ip route 0.0.0.0 0.0.0.0 125.117.16.57 ! ! access-list 1 permit 192.168.1.0 0.0.0.255 ! line con 0 ..... **************************************

Thanks in advance Karthik

formatting link

Reply to
Marskarthik
Loading thread data ...

I need help from someone to set nating in multilink environment

My router internal ip address is : 192.168.1.2 My router external ip address is : 125.117.1.177 My router multilink ip address is : 125.117.16.58 IP that i want to appear outside for internet browsing: 125.117.1.178

All i need is correct code to set nat on this router so that i can browse internet from 192.168.1.X series machines. I need this badly......

Below is the code on my Cisco 2610 router

************************ Current configuration : 1605 bytes ! version 12.3 service timestamps debug datetime msec service timestamps log datetime msec no service password-encryption ! hostname marskarthikrouter ! boot-start-marker boot-end-marker ! ! memory-size iomem 10 no aaa new-model ip subnet-zero ip cef ! ! ip domain name marskarthik.com ip name-server 202.56.250.5 ip name-server 202.56.230.5 ! ! username cisco privilege 15 secret 5 $1$IQtx$IuJCcgVGertyW1jfoGHTK0 ! ! ! interface Multilink1 ip address 125.117.16.58 255.255.255.252 ppp multilink ppp multilink group 1 ! interface Ethernet0/0 description *****Local marskarthik Network***** ip address 192.168.1.2 255.255.255.0 secondary ip address 125.117.1.177 255.255.255.240 ip nat inside no ip route-cache cef no ip route-cache no ip mroute-cache full-duplex ! interface Serial0/0 bandwidth 2048 no ip address encapsulation ppp no ip route-cache cef no ip route-cache no ip mroute-cache no fair-queue ppp multilink ppp multilink group 1 ! interface Serial0/1 bandwidth 2048 no ip address encapsulation ppp no ip route-cache cef no ip route-cache no ip mroute-cache no fair-queue ppp multilink ppp multilink group 1 ! ! ip http server ip classless ip route 0.0.0.0 0.0.0.0 125.117.16.57 ! ! access-list 1 permit 192.168.1.0 0.0.0.255 ! line con 0 ..... **************************************

Thanks in advance Karthik

formatting link

Reply to
Marskarthik

I think that would do it. Never been much of a NAT person but

interface Multilink1

ip nat outside

ip nat pool Local 125.117.1.178 125.117.1.178 prefix 20

ip nat inside source list 1 pool Local overload

Reply to
Blue

Reply to
Marskarthik
