blocking incoming udp packets

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View
Hello Group:

My system: Desktop and laptop networked through Linksys wired router.

Question: My software firewall (Deerfield Visnetic) is constantly
logging blocks of incoming udp packets, the source being 192.168.1.1
(which is presume is the router), destination being 255.255.255.255 or
192.168.1.255.

This doesn't seem to interfere with anything, but just watching the
constant bombardment in the logging screen is annoying.

Can anyone explain what is going on here? Or what, if anything, I can
or should do about it?

I can set the firewall to block and stop logging all udp packets which
do not have a specific rule. This eliminates the  constant screen
filling. But I'm not sure if I should do this. I really don't
understand what is happening, which is why I'm asking for help.

I guess I'm just concerned that my system may not be tweaked properly
and could be wasting resources. Perhaps I should change something in
the router setup via the web based configuration program.

Here are a couple of the log entries, copied:

2008/07/08, 05:32:18.406, GMT -0400, 2010, Device 3,
Blocked incoming UDP packet (no matching rule),
src=192.168.1.1, dst=255.255.255.255, sport=520,
dport=520

2008/07/08, 05:40:15.921, GMT -0400, 2010, Device 3,
Blocked incoming UDP packet (no matching rule),
src=192.168.1.1, dst=192.168.1.255, sport=8385,
dport=162

Thanks for any explanations, links to sites to educate me, or
suggestions.

Jack



Re: blocking incoming udp packets
Quoted text here. Click to load it

Seems to be a router broadcasting routing information.

Quoted text here. Click to load it

Seems to be a network device broadcasting SNMP messages on the local
network.

For further information you need to inspect the packets' contents with a
protocol analyzer (Wireshark, tcpdump, etc.).

Does your Linksys router have the IP address 192.168.1.1? Unless you
need RIP or SNMP on your LAN you should check your router's
configuration.

cu
59cobalt
--
"If a software developer ever believes a rootkit is a necessary part of
their architecture they should go back and re-architect their solution."
--Mark Russinovich

Re: blocking incoming udp packets
Quoted text here. Click to load it

Yes, 192.168.1.1 is the router.
UPnP and SNMP are disabled.

I will try to investigate the packets as you suggest.

Thanks.

Jack


Re: blocking incoming udp packets
JClark wrote:

Quoted text here. Click to load it

Is UPnP enabled in the router?  Try disabling it or check that it is
disabled.

http://en.wikipedia.org/wiki/Upnp

Re: blocking incoming udp packets

Quoted text here. Click to load it
Yes, UPnP is disabled in the router.
I appreciate your help.
Still not getting a grasp of the overall situation.

Jack

Re: blocking incoming udp packets
JClark wrote:

Quoted text here. Click to load it

I'm wondering in "2008/07/08, 05:40:15.921, GMT -0400, 2010, Device 3"
as to what is "device 3".  Might it be whatever is plugged into the port
numbered 3 on the router?  If so, is that your host or another one?  If
another one, try yanking the cable out of port #3 on the router to see
if it all quiets down.

Re: blocking incoming udp packets

Quoted text here. Click to load it
Hello VanguardLH,

The firewall (Deerfield Visnetic) recognizes and lists four devices or
"adapters".
#1 is labeled \\DEVICE\\NDISWANBH (? a WAN miniport)
# 2 is labeled Dialup Adapter
#3 is labeled Local Area Connection
#4 is labeled Local Area Connection

(#3 and #4 correspond to two LAN connections on the motherboard, which
correspond to two networking adapters seen in Device Manager. Only the
one corresponding to Local Area Connection #3 on the firewall is being
used.)

I have configured the firewall  to block everything on  adapters #1
and #2 and #4.

The one I use is Device #3, LAN.

Returning to the original question, a summary, as I see it (not
necessarily correctly):

It seems the router is sending udp packets to 255.255.255.255 (both
source and destination ports =  520, or to 192.168.1.255 (source port
ranging from 7000 to 7259, and destination port 162.

I have no idea what this all means.

Again, I appreciate your help.

Jack




Re: blocking incoming udp packets
JClark wrote:
...
Quoted text here. Click to load it

Ansgar already explained, but since you wrote

Quoted text here. Click to load it

I will repaeat one more time, and I will provide some links to
additional informations.

That is broadcast[1]

UDP 520 is a port used by Routing Information Protocol (RIP) [2] and [3].

UDP 162 is a port used by Simple Network Management Protocol (SNMP) [4]
and [5]

IMO everything is OK. But to be sure follow Ansgar advice and inspect
packet content, you can use, for example, Wireshark[6].

[1] http://en.wikipedia.org/wiki/Broadcast_address
[2] http://www.auditmypc.com/port/udp-port-520.asp
[3] http://en.wikipedia.org/wiki/Routing_Information_Protocol
[4] http://www.auditmypc.com/port/udp-port-162.asp
[5] http://en.wikipedia.org/wiki/Simple_Network_Management_Protocol
[6] http://www.wireshark.org /

Re: blocking incoming udp packets

Quoted text here. Click to load it
Many thanks! I will spend some time on the links you have provided and
perhaps become better informed.
I may also post something in the Linksys forum (presuming there is
one) to see if I have the router configured correctly.
Again, thanks.

Jack

Re: blocking incoming udp packets
JClark wrote:

Quoted text here. Click to load it

Oops, my bad.  I thought the "log" was from the router's firewall, not
from your software firewall on your intranet host.  Have you checked
your router's logs?  Did you enable logging in the router?  Sometimes
the router's logs are not so easy to read plus it might be limited in
the number of records retained.  WallWatcher works with some routers to
extract their logs so you can review them locally.

Re: blocking incoming udp packets

Quoted text here. Click to load it
Nothing unusual in the router logs.
Thanks for suggestion.

Jack

Re: blocking incoming udp packets

Quoted text here. Click to load it

UDP 162 is the SNMP trap port.   If you're not familiar with simple
network management protocol, this traffic to 162 may simply be the
network device attempting to send traps to be logged by an SNMP
management station.

UDP 520 is RIP routing.   The router is advertising routes with this
exceedingly simple, easy to spoof protocol.

Both should be functionality that can be disabled in the source
network device.

Best Regards,
--
Todd H.
http://www.toddh.net /

Re: blocking incoming udp packets
On Wed, 09 Jul 2008 13:06:15 -0500, comphelp@toddh.net (Todd H.)
wrote:

Quoted text here. Click to load it
Sounds like good advice. I'll work on the Linksys setup with their
web-based configuration program.
I'm still not understanding it all in depth, but your comments and the
earlier replies have given me a good base to work with.
Thank you.

Jack

Re: blocking incoming udp packets
On Wed, 09 Jul 2008 13:06:15 -0500, comphelp@toddh.net (Todd H.)
wrote:

Quoted text here. Click to load it
Todd,
Some good news. I was able to disable RIP routing in the router, and
now all the traffic over UDP 520 has stopped.
Now I need to work on the SNMP 162. It isn't quite as clear.
But it seems I'm on the right track.
Many thanks again.

Jack

Re: blocking incoming udp packets

Quoted text here. Click to load it

Disabling SNMP in general on the device is a good idea if you're not
using it.  Did I miss in this thread where the make/model of the
router was mentioned?


--
Todd H.
http://www.toddh.net /

Re: blocking incoming udp packets
On Wed, 09 Jul 2008 22:14:13 -0500, comphelp@toddh.net (Todd H.)
wrote:

Quoted text here. Click to load it
Hi Todd,

It's a Linksys BEFSX41.
The RIP disabling was easy to do, and that has stopped the traffic on
port 520.
Under "Administration" I have SNMP "disable" checked, so SNMP ought to
be disabled. I also have UPnP disabled.

But I'm still getting the port 162 traffic.

Thanks again.

Jack

Re: blocking incoming udp packets

Quoted text here. Click to load it

Barring an answer from an owner here, your next step is to a linksys
support forum on this model and asking users there how to disable the
sending of traps.

You will also want to make sure you have the latest firmware for that
device as it has quite a checkered history with respect to exploitable
firmware vulnerabilities.

Best Regards,
--
Todd H.
http://www.toddh.net /

Re: blocking incoming udp packets
On Thu, 10 Jul 2008 09:06:00 -0500, comphelp@toddh.net (Todd H.)
wrote:

Quoted text here. Click to load it
Todd,

You and the other reply posters have been very helpful. I'm getting a
better understanding of the process. I'll try to follow through with
suggestions, including posting in the Linksys forum and updating the
firmware.

One last question:  Could you recommend a replacement for the Linksys
router ("checkered history")? Or even a hardware firewall/router? I
know there would be some new learning involved.

Again, many thanks


Jack

Re: blocking incoming udp packets

Quoted text here. Click to load it

I'm a fan of the third party firmware projects out there like dd-wrt
and tomato.

Check the hardware compatability matrix for these firmware
projects--your Linksys could get a new lease on life perhaps just by
blowing away the factory firmware and replacing it with one of these
free open source projects.

Otherwise, a Linksys WRT54GL from newegg.com   lets you play nicely
with these.
http://www.dd-wrt.com /
http://www.polarcloud.com/tomato

Or, just update to the latest linksys firmware to fix the known flaws
your current firmware may have.

--
Todd H.
http://www.toddh.net /

Re: blocking incoming udp packets
On Thu, 10 Jul 2008 18:12:53 -0500, comphelp@toddh.net (Todd H.)
wrote:

Quoted text here. Click to load it
Your post was copied and will work on it. Thanks for the umpteenth
time!

Jack
