Trying to Find Class 1 Laser Diode

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View
I need to make a laser pointer for a profoundly disabled friend.  It
needs only to point 3 inches so I'm looking for a Class 1 laser diode
that will be safe for him despite his erratic movements.  Any help in
locating a Class 1 laser diode that would be appropriate would be
REALLY appreciated.

Thanks.

Trish

Re: Trying to Find Class 1 Laser Diode
Dmitri(cabling-Design.com) had written this in response to
http://forums.cabling-design.com/fiberoptics/Trying-to-Find-Class-1-Laser-Diode-941-.htm
 :

Patty wrote:


Quoted text here. Click to load it




I know I'm terribly late with an answer here but in case you're still
looking for a solution: you're probably not going to find a laser diode
with less than 1mW power. What I would do to eliminate any remote chance
of doing eye damage is to alter (de-focus) the optics of a smallest laser
pointer you can find to increase the beam spot size. Since you're only
concerned with the closest proximity, a beam spot of, say 1/4" diameter
may still be useful for pointing at close range but absolutely safe due to
its high divergence at the distance to the eye.

Otherwise you'll have to find a way to modulate the laser diode or just
use a bright LED instead of a laser diode. The latter seems an easier
solution for a hand-held pointer.

-------------------------------------
Best Regards,
Dmitri Abaimov, RCDD
http://www.cabling-design.com/homecabling/
Home Cabling Guide, Cabling Forum, color codes, pinouts and other useful
resources for premises cabling users and pros



--
+----------------------------------------------------------+
