HTTP forwarding, based upon host header

Oh... don't forget to make sure you configure your external DNS for the new site. Each host header needs a record.

-Frank

Your firewall should support port mapping. This is where you set up port 81 to be forwarded inside to server #2 after mapping it to port 80. Rather than the usual one-to-one incoming mapping.

Then outside users have to use

-Russ.

I've got a Watchguard X50 Edge hardware firewall connected to the internet via T1.

Inside the firewall, I've got 2 web servers, Windows 2000 Server.

The X50 has the capability to be associated to ONLY ONE external IP address (argh...).

I can easily forward all incoming PORT 80 traffic to either one of the web servers.

However, I need to be able to forward SOME incoming traffic to Web Server #1, and SOME incoming traffic to Web Server #2. Of course, this would be determined by the host header information.

So, xyz.com and abc.com are on Server #1. def.com and ghi.com are on Server #2.

Can anyone suggest a free or cheap software solution to this problem?

Thank you.

John

open original image

I've got a Watchguard X50 Edge hardware firewall connected to the internet via T1.

Inside the firewall, I've got 2 web servers, Windows 2000 Server.

The X50 has the capability to be associated to ONLY ONE external IP address (argh...).

I can easily forward all incoming PORT 80 traffic to either one of the web servers.

However, I need to be able to forward SOME incoming traffic to Web Server #1, and SOME incoming traffic to Web Server #2. Of course, this would be determined by the host header information.

So, xyz.com and abc.com are on Server #1. def.com and ghi.com are on Server #2.

Can anyone suggest a free or cheap software solution to this problem?

Thank you.

John

I am familiar with hosting multiple web sites on a single server using a single IP address.

However this situation is a little different.

I have two web servers on the same 192.168.111.x network.

Server #1: 192.168.111.1 - xyz.com and abc.com Server #2: 192.168.111.2 - def.com and ghi.com

External DNS is configured so that the WWW hosts for these 4 domains point to 207.56.34.12 (for example).

The firewall port forwarding is set up to forward all PORT 80 requests to

xyz.com and abc.com are fully accessible from the outside world.

But back to my original question, how can I access

I don't know about IIS but Apache web server allows virtual name-based virtual hosts to be on different physical servers. Maybe IIS does also.

Then just use a virtual host concept i.e. like the one from Apache, and proxy the right traffic to the second webserver.

Yours, VB.

Configure the "wrong" webserver, which is reached by all the traffic, as a proxy for those websites.

Yours, VB.

I understand that this is conceptually what I need to do...but how does it work in practice? Do you have any suggestions on how to start ?

john lemon wrote: [IIS virtual hosts and proxiing to a second server]

HTH, VB.
