802.11 b headers

Nov 18, 2005 2 Replies

For 802.11b speeds (1, 2, 5.5, 11), the answer is yes. ALL management frames are sent at 1Mbit/sec to insure that all radios hear these frames. However, 802.11a/g management frames are sent at the connection speed. All are unencrypted. When 802.11w gets approved, these frames will also be encrypted.

Go to the source. IEEE 802.11 specs at:

formatting link
This looks like a good start:
formatting link

802.11 b headers open original image

Hello can any one tell me if the plpc and the header are transferred at 1 mbps, whilst the data part then goes at full speed. I have been doing some reading in this area and the results are contradictory to each each. Some places says it does others do not mention it at all ?



Thanks - Adrian
