right, let me give you some background in this network.
i have 2 adsl lines from dirrfrent providers
Line #1 has 1 Static Ip
Line #2 has 8 Static Ip's
on line #1 i have a draytek 2800
on line #2 i have a draytek 2800
line #1 Lan ip is x.x.x.205 line #2 wan ip is x.x.x.44
line #2 Lan ip is x.x.x.204 Line #2 wan ip is x.x.x.217
Main VPN Server is located on x.x.x.50
Mail filtering Server is on x.x.x.58
Web mail Server is on x.x.x.220
Ok for thouse of you who have followed this carry on, for thouse of you
who are completley lost, go to
on the both vigor routers i have setup port forwarding on the following
ports
- 1723 - x.x.x.50
- 80 - x.x.x.220
- 25 - x.x.x.58
on each of the servers (there are quite a few) i have specified the default gateway as x.x.x.205 metric 1 x.x.x.204 metric 2
now i can connect via , vpn (pptp 1723 ), http ( 80 ) and mail inbound on 25 on the first line x.x.x.44 however when i try to connect to either port 1723,80,25 on the second line the router seems to accept the redirect pass it on to the correct ip and from there no magic is happening, there is no return to the client. its as if the packets get lost in a big black hole
i am connecting to the both lines using a 3rd line which is totally seperate from the entire network ( joys of being the IT manager )
Does any body have a dammed clue as to what is going on, please feel free to email me on this subject your help would be appriciated.
Cheers
Nelix
