UK, England - Wireless Link @ 5GHz


Hi Guys,
I am not sure if electromagnetic regulations are exactly the same in all EU
countries, that's why I will rather ask...
I am planning to build a wireless link between two buildings @5GHz, it would
be more less 15 miles.
My questions are:
- what band at 5GHz can I use in the UK?
- can I use up to 1W EIRP?
- is it possible to use more than 1W EIRP? (if I have a licence or sth). If
yes, where can I get the licence from?
Thank you,
Martin
Reply to
Martin Lukasik
Loading thread data ...
Hello Martin,
ML> is it possible to use more than 1W EIRP? (if I have a
I was about to suggest checking on the Radiocommunication Agency site because they used to have nice little guides to various radio services (perhaps including the one you're interested in). Apparently the RA has been replaced by something called Ofcom
formatting link
. Hopefully there's something relevant on their site. Failing that, you could probably telephone them.
Hope this helps, - Andy.
Reply to
Andy Ball
Try this...
formatting link
Reply to
Andy Ball
Okay, I missed...
formatting link
Reply to
Andy Ball
Brilliant. That is what I was looking for... Thank you. So they require a licence, but it's not expensive and EIRP is 2W. (In EU is 1W, some countries 100mW).
Thank you, Martin
Reply to
Martin Lukasik
I wonder if you could make do with a Wi-Fi access point on each end and use high gain yagi antennas to cover the distance. I have heard of people being able to "talk" many miles using such a setup.
formatting link
Reply to
Jim Volstad
Hello Jim,
JV> I wonder if you could make do with a Wi-Fi access
A high-gain Yagi increases your effective radiated power (increases the the amount of your radiated power that goes in a given direction), which might effect license requirements.
- Andy.
Reply to
Andy Ball
aiui, in the US that's permissible for point-to-point connections, too, so it's worth checking if the same is true in the UK.
Reply to
Derek Broughton
