installing ethernet RJ45 and faceplate

and it seemed to work well enough.

Hi Jim;

The RJ45 IDC jacks require a 110 punchdown tool (not included). A screwdriver will not do. No offence meant, but ethernet does not work like an analog phone line; you can't loop it from one jack to another. Unless, of course, you use the orange and green wires for one jack and blue and brown for the other. Or you could run a wire from the second faceplate to your router, so you have separate cables (best solution if it's an easy run.

Regards,

Neil

Hi Neil,

I'm not trying to loop it. I want to make an extension. The wiring will go from the Switch to faceplate 1 to faceplate 2 to the Wireless access point. It would be the same as if I ran a single Ethernet cable direct from the Switch to the Wireless access point.

So with this kind of wiring scheme, I'm not sure how to connect the two faceplates. Would it be a cross-over or straight through?

right now I'm using straight through. So I'll try a cross-over next and see if that does it.

Of course, I think I will need a punchdown tool. It's funny, I found this punchdown tool

it looks just like the bit that I am using. Is a punchtool a kind of razor blade? Or is it a blunt tool? I should think that as long as the wires get down into the slots on the RJ45 receptacvle that it should work. Does the punchdown tool do something else to the wires besides simply pushing the wire into the slot?

Thanks!

Jim

Neil J. Hubbard wrote:

> and it seemed to work well enough.

What you want to make sure of is to have the wiring scheme of 568B on both jacks. On the jack there is a color scheme one is marked A and the other B. Actually either will work but I prefer B and use it all the time. This will give you a straight thru configuration.

As for the punch down tool it would be best to use one for a good quick connection. However if you are not doing more than two jacks it is not cost effective. The punch down tool looks similar to the tool that you have shown except that it has a sharp blade on one side that trims off the wire at the block to make it neat. Also the 110 punch down tool as a thinner center portion that will push the wire between the connection wedge. If you are using the wider tool it may be spreading the connection wedge so much that it is not cutting the insulation on the wire thus not connecting with the conductor.

You may want to start over by stripping the outer sheath about 4"-5" and then un-twist and straighten the pairs. Then lay out the pattern being sure to follow the 568B configuration pattern. SOLID BLUE to SOLID BLUE and WHITE with BLUE to the WHITE with BLUE and so on for all the pairs. Depending on your wire and its colors this can some times be a little challenging. Place the end of the sheath as close to the jack as you can and start laying in the wires.

Once they are all in the proper position pull each individual wire down into the slot. You will see that (if you look closely) that it will make contact with the small wedge connector. As the wire is pushed or pulled into the wedge it will start to cut into the insulation and separate. If you have not damaged it with your tool it should grip it tight.

If you have a small screwdriver with a thin blade you can apply pressure on the wire only and push it into the wedge. Once all wires are in and secure cut off the excess and you should be done.

There is a possibility that by using you first tool you may have damaged the wedge and the jack is trashed. Except it as payment for your education.

If you are using a switch then be sure to use straight thru patch cords.

Hope the above helps. Let me know if what I wrote is confusing. From my location it looks very clear but sometimes........................................

Good luck.

Les

> > and it seemed to work well enough.

> and it seemed to work well enough.

He said he was using a notched screwdriver. That's not as bad as a regular screwdriver in that it can be guided down more reliably. But I agree. Even a cheap punch down tool would be better.

By that I assume you're talking about splitting pairs and using the second quartet of wires to carry another "channel."

If I read the poster correctly (and that's always in doubt!) he could just string a long patch cord between the floors but he's trying to make it look nice. By using the faceplate jacks on floor one and two as the middle segment of a long patch cord I assume he's going to plug into an open jack on the router. If that's the case, all he has to do is follow the same color scheme on each jack so that the patch cord free end of the patch cords plugged into each outlet are essentially one long patch cord.

I think when he said "two outlets" he was referring to a single outlet on each floor. Your advice holds true, however, if he want to plug something else into the router and switch on floor two, although I suppose with a WAP that might be moot.

-- Bobby G.

Hi Jim,

Wire it all straight-through, using the "B" standard as indicated on the RJ45 jack.

I suspect your tool is damaging the contacting blades inside the jack. Home Depot has a plastic punch down tool, I've seen it for sale for a couple bucks. They also come included with the 10 packs of RJ45 jacks.

E. Lee Dickinson Entertainment Design and Technology

and it seemed to work well enough.

That's an excellent point that I overlooked. He may indeed may have it wired "correctly" in terms of which wire is where, but not "well." It's very likely that the insulation was not pierced and there's no conductivity. I've on occasion had to use needle nose pliers to push down a wite. It's ugly, it's not good practice but it's better than nothing, especially if you don't have a punchdown tool handy. This is where one of those little 8 LED testers is very helpful.

-- Bobby G.

HI, Thank you all for your responses. You all have been very helpful. Robert and Able were right in that I may have damaged the RJ45 receptacles by not using the right tool. Once I was sure I had the wiring correct, I went around and made sure each wire was pushed into the wedge. On one end I had to start over by cutting the end of the cable and striiping off the outter insulation.

For right now the connection seems good, in fact I'm writing this response from my laptop. But I will definately want to replace those jacks soon, and next time I will make sure I use a a punchdown tool.

Thanks everyone!!

Jim

Able gets credit for calling it right. I only get partial credit for realizing it *after* he mentioned it. :-)

It's good to be able to know how to improvise, too. Congrats.

-- Bobby G.

Thanks for the credit. It is good to know I got this one right. So far this year I made 2,345,726 mistakes and it is only June 25th.

Congrats on getting it all working. And yes, get some new jack when you can. You will be glad you did.

Later,

Les
