For HA usage, I design a small PCB a few times a year, and have been using PC Logic "Circuit Layout" (v3.1) for some time...
There seems to be no support or upgrades available (last was 4 years back), and I'm looking for a product to replace it (yes, I did buy Circuit Layout, so it doesn't need to be freeware.)
My requirements are simple
- usually "regular" components, but chance of an occasional SMT part
- usually single sided, and at most dual sided.
-print to printer or export image of PCB for documentation
-runs on win2k
Wish list: I'd like the tool to also be able to draw schematics
Anybody got a suggestion for SW? (
