10HD vs. 100FD


Hello,
1) suppose two ports with the settings from the subject line attempt to
communicate. I can't find in the 802.3 standard description of the exact
behavior in such situation (obviously full-duplex won't possible at all,
only HD ?)
2) suppose one port with AutoNegotiation enabled, second has fixed setting
100Mbps/full-duplex. Am I right, that auto negotiation session will fail,
since the second port doesn't have on? If it so, then what settings will be
applied on the first port?
Thanks.
Reply to
Mark
Loading thread data ...
look here for answers,
formatting link
Reply to
Reed
It doesn't address speed-sensing, but some boilerplate about duplex negotiation - the 10HD side can be though of as being hardcoded to HD for the purposes of the below.
How 100Base-T Autoneg is supposed to work:
When both sides of the link are set to autoneg, they will "negotiate" the duplex setting and select full-duplex if both sides can do full-duplex.
If one side is hardcoded and not using autoneg, the autoneg process will "fail" and the side trying to autoneg is required by spec to use half-duplex mode.
If one side is using half-duplex, and the other is using full-duplex, sorrow and woe is the usual result.
So, the following table shows what will happen given various settings on each side:
Auto Half Full
Auto Happiness Lucky Sorrow
Half Lucky Happiness Sorrow
Full Sorrow Sorrow Happiness
Happiness means that there is a good shot of everything going well. Lucky means that things will likely go well, but not because you did anything correctly :) Sorrow means that there _will_ be a duplex mis-match.
When there is a duplex mismatch, on the side running half-duplex you will see various errors and probably a number of _LATE_ collisions ("normal" collisions don't count here). On the side running full-duplex you will see things like FCS errors. Note that those errors are not necessarily conclusive, they are simply indicators.
Further, it is important to keep in mind that a "clean" ping (or the like - eg "linkloop" or default netperf TCP_RR) test result is inconclusive here - a duplex mismatch causes lost traffic _only_ when both sides of the link try to speak at the same time. A typical ping test, being synchronous, one at a time request/response, never tries to have both sides talking at the same time.
Finally, when/if you migrate to 1000Base-T, everything has to be set to auto-neg anyway.
Reply to
Rick Jones
