Good day expert guys!
I need you to confirm points in there. I have to setup a VPN from a PIX 506 to a PIX 515.
I need you to confirm it looks ok in order to achieve:
- access-list traffic-2-remote will "take over" the access-list internet-access
- internet-access ACL will be fine,
- my access-group are ok.
I am in trouble with the access-group since only on is in there. I believe I should have 2, no?
Is there something missing from the show conf?
Thank you very much
The config in a text file can get downloaded at
: Saved : Written by enable_15 at 05:23:29.126 UTC Fri May 27 2005 PIX Version 6.3(4) interface ethernet0 auto interface ethernet1 auto nameif ethernet0 external security0 nameif ethernet1 inside security100 enable password xxxxxxxxxxxxxxx encrypted passwd xxxxxxxxxxxxxxxxxx encrypted hostname pix1 domain-name mycompany.net fixup protocol dns maximum-length 512 fixup protocol ftp 21 fixup protocol h323 h225 1720 fixup protocol h323 ras 1718-1719 fixup protocol http 80 fixup protocol rsh 514 fixup protocol rtsp 554 fixup protocol sip 5060 fixup protocol sip udp 5060 fixup protocol skinny 2000 fixup protocol smtp 25 fixup protocol sqlnet 1521 fixup protocol tftp 69 names access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.1.0.0
255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.1.48.0 255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.1.96.0 255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.6.0.0 255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.8.0.0 255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.100.96.0 255.255.255.240 access-list traffic-2-remote permit ip 192.168.10.0 255.255.255.128 10.100.112.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.1.0.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.1.48.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.1.96.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.6.0.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.8.0.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.100.96.0 255.255.255.240 access-list no-nat permit ip 192.168.10.0 255.255.255.128 10.100.112.0 255.255.255.240 access-list internet-access permit tcp 192.168.10.0 255.255.255.128 any eq www access-list internet-access permit tcp 192.168.10.0 255.255.255.128 any eq https access-list internet-access permit tcp 192.168.10.0 255.255.255.128 any eq 5223 access-list internet-access permit tcp 192.168.10.0 255.255.255.128 any eq ssh access-list internet-access permit tcp 192.168.10.0 255.255.255.128 any eq ftp access-list internet-access permit udp 192.168.10.0 255.255.255.128 any eq domain pager lines 24 logging on logging timestamp logging buffered informational logging trap informational logging host external 195.238.14.56 no logging message 302010 mtu external 1500 mtu inside 1500 ip address external 195.238.98.34 255.255.255.252 ip address inside 192.168.10.125 255.255.255.128 ip audit info action alarm ip audit attack action alarm pdm logging informational 100 pdm history enable arp timeout 14400 global (external) 1 interface nat (inside) 0 access-list no-nat nat (inside) 1 0.0.0.0 0.0.0.0 0 0 access-group internet-access in interface inside route external 0.0.0.0 0.0.0.0 195.238.98.35 1 timeout xlate 0:05:00 timeout conn 1:00:00 half-closed 0:10:00 udp 0:02:00 rpc 0:10:00 h225 1:00:00 timeout h323 0:05:00 mgcp 0:05:00 sip 0:30:00 sip_media 0:02:00 timeout uauth 0:05:00 absolute aaa-server TACACS+ protocol tacacs+ aaa-server TACACS+ max-failed-attempts 3 aaa-server TACACS+ deadtime 10 aaa-server RADIUS protocol radius aaa-server RADIUS max-failed-attempts 3 aaa-server RADIUS deadtime 10 aaa-server LOCAL protocol local ntp server 195.238.14.56 source external snmp-server host external 195.238.14.56 poll no snmp-server location no snmp-server contact snmp-server community 373v4ih8 no snmp-server enable traps floodguard enable sysopt connection permit-ipsec crypto ipsec transform-set trans-aes-md5 esp-aes esp-md5-hmac crypto map cmap-vpn 10 ipsec-isakmp crypto map cmap-vpn 10 match address traffic-2-remote crypto map cmap-vpn 10 set peer 212.217.98.167 crypto map cmap-vpn 10 set transform-set trans-aes-md5 crypto map cmap-vpn interface external isakmp enable external isakmp key ******** address 212.217.98.167 netmask 255.255.255.255 isakmp identity address isakmp keepalive 10 isakmp nat-traversal 20 isakmp policy 10 authentication pre-share isakmp policy 10 encryption aes isakmp policy 10 hash md5 isakmp policy 10 group 2 isakmp policy 10 lifetime 86400 telnet timeout 5 ssh 195.238.98.0 255.255.255.0 external ssh timeout 60 console timeout 0 terminal width 80 Cryptochecksum:xxxxxxxxxxxxxxxxxxxxxxxxxxx pix1(config)#
