pix 506E to VPN3000 cant connect

Guys here's the debug output im getting.. what seems to be wrong ?

ISAKMP (0:0): sending NAT-T vendor ID - rev 2 & 3 ISAKMP (0): beginning Main Mode exchange crypto_isakmp_process_block:src:198.235.13.31, dest:203.115.153.42 spt:500 dpt:500 OAK_MM exchange ISAKMP (0): processing SA payload. message ID = 0

ISAKMP (0): Checking ISAKMP transform 1 against priority 20 policy ISAKMP: encryption AES-CBC ISAKMP: keylength of 192 ISAKMP: hash SHA ISAKMP: default group 2 ISAKMP: auth pre-share ISAKMP: life type in seconds ISAKMP: life duration (VPI) of 0x0 0x1 0x51 0x80 ISAKMP (0): atts are acceptable. Next payload is 0 ISAKMP (0): processing vendor id payload

ISAKMP (0): SA is doing pre-shared key authentication using id type ID_IPV4_ADDR return status is IKMP_NO_ERROR crypto_isakmp_process_block:src:198.235.13.31, dest:203.115.153.42 spt:500 dpt:500 OAK_MM exchange ISAKMP (0): processing KE payload. message ID = 0

ISAKMP (0): processing NONCE payload. message ID = 0

ISAKMP (0): processing vendor id payload

ISAKMP (0): processing vendor id payload

ISAKMP (0): received xauth v6 vendor id

ISAKMP (0): processing vendor id payload

ISAKMP (0): speaking to another IOS box!

ISAKMP (0): processing vendor id payload

ISAKMP (0): speaking to a VPN3000 concentrator

ISAKMP (0): ID payload next-payload : 8 type : 1 protocol : 17 port : 500 length : 8 ISAKMP (0): Total payload length: 12 return status is IKMP_NO_ERROR crypto_isakmp_process_block:src:198.235.13.31, dest:203.115.153.42 spt:500 dpt:500 ISAKMP: error, msg not encrypted crypto_isakmp_process_block:src:198.235.13.31, dest:203.115.153.42 spt:500 dpt:500 ISAKMP: sa not found for ike msg

Reply to
jayp_kkk
Loading thread data ...

Jayr,

Would you post a portion of your config? It looks like you didn't define "interesting traffic" which should be encrypted ("msg not encrypted" message at the bottom of your output).

Good luck,

Mike CCNP, CCDP, CCSP, Cisco Voice, MCSE W2K, MCSE+I, Security+, etc. CCIE R&S (in progress), CCIE Voice (in progress)
