missing "rtr" command for Tracking IP SLA

Dec 22, 2008 2 Replies
R
missing "rtr" command for Tracking IP SLA open original image

We're running IOS 12.4(15)T on a 2811 and trying to use Reliable Static Routing Backup as per

formatting link
We've configured an SLA and can verify its working using "show ip sla statistics", however we can't go the next step and track the state of this SLA because the router doesn't support the rtr command in the following line:



"track 123 rtr 1 reachability"



The only track options available are: interface, ip, list or stub-object, none of which seem to be what we need.



Has the "rtr" command been superceded, do we have a non supporting IOS or what?



Any help would be much appreciated


Vote
Twitter Facebook LinkedIn
B

What feature set do you have?

Post lines like - Cisco IOS Software, C870 Software (C870-ADVIPSERVICESK9-M), Version

12.4(15)T7, ... System image file is "flash:c870-advipservicesk9-mz.124-15.T7.bin"

from sh ver

The document that you pointed at says that it is not available in IPbase on the 1700.

It seems to be available in Advanced iP Services on the 870.

You can check on

formatting link

Vote
Twitter Facebook LinkedIn
R

per

formatting link
>

You were right, the feature set was IPBase and when I upgraded to Advanced Services the rtr command was there! Thanks

Vote
Twitter Facebook LinkedIn
