I need to assign a public ip to a client machine

Hi,

I have a Cisco 2511 router with current configuration below and I need to assign a public ip address to my windows machine. So that i can access my machine anywhere from the world by remote desktop and vnc. How to do that? any one tell me the code to do that.

My machine ip is 192.168.1.110 and i want to assign public ip

185.17.1.180

My current configuration is below. __________________________________________________ Cisco 2511 Current configuration: ! version 12.0 service timestamps debug uptime service timestamps log uptime no service password-encryption ! hostname cisco2 ! enable secret 5 $1$6JBL$Fb0.amMsITZx6vtSNm7n3/ ! ip subnet-zero ip name-server 202.54.6.60 ip name-server 202.54.1.30 ! ! ! interface Ethernet0 ip address 192.168.1.2 255.255.255.0 secondary ip address 185.17.1.177 255.255.255.240 no ip directed-broadcast ip nat inside no ip route-cache no ip mroute-cache ! interface Serial0 ip address 185.17.0.30 255.255.255.252 no ip directed-broadcast ip nat outside no ip route-cache no ip mroute-cache no fair-queue ! interface Serial1 no ip address no ip directed-broadcast no ip mroute-cache shutdown ! ip nat pool KARTHIK 185.17.1.179 185.17.1.179 netmask 255.255.255.240 type rotary ip nat inside source list 1 pool KARTHIK overload ip classless ip route 0.0.0.0 0.0.0.0 Serial0 ip route 185.17.1.0 255.255.255.0 185.17.1.81 ! access-list 1 permit 192.168.1.0 0.0.0.255 ! line con 0 transport input none line 1 16 no exec exec-timeout 0 0 transport input all line aux 0 modem InOut transport preferred telnet transport input all speed 38400 flowcontrol hardware line vty 0 4 password marskarthik login ! end __________________________________________________________________

Thanks, Karthik

formatting link

Reply to
Marskarthik
Loading thread data ...

You can use static nat with: ip nat outside source static 185.17.1.180 192.168.1.110

Doan

Reply to
Doan

Thanks Doan.... This works.

Karthik
