Unable to add vlans on my Cisco 871w router

Hello All,

I'm hoping I can get some information on something that's a little bizarre about my new Cisco 871W Router. This is a Cisco router with Wan port, 4-port switch, a dot11radio interface. According to the product description on cisco's website, it is supposed to have vlan support:

formatting link

According to the show vtp status command, the device states that it supports up to 256 vlans yet when I try to create additional vlans I get a message that additional vlans cannot be added.

acsrouter#show vtp status VTP Version : 2 Configuration Revision : 0 Maximum VLANs supported locally : 256 Number of existing VLANs : 5 VTP Operating Mode : Server VTP Domain Name : acs VTP Pruning Mode : Disabled VTP V2 Mode : Disabled VTP Traps Generation : Disabled MD5 digest : 0xAA 0x3F 0x8E 0x57 0xDC 0xFA 0x53 0x4B Configuration last modified by 0.0.0.0 at 0-0-00 00:00:00 Local updater ID is 10.10.10.1 on interface Vl1 (lowest numbered VLAN interface found)

acsrouter(vlan)#vlan 2 name Private Vlan can not be added. Maximum number of 1 vlan(s) in the database.

Can anyone tell me for sure if this means that I'm not allowed to create additional vlans?

Thanks in Advance,

Adil
