Linsys with 5 static ip addresses. How to configure?
Bookmark this page:
 Yahoo!
 Google
 Windows Live
 del.icio.us
 digg
 Netscape
|
|
|||||||||||||
|
Posted by on September 21, 2005, 10:12 am
Please log in for more thread options I have a quick question as a newbie about networking, that I was hoping someone might be able to help out with. I have recently upgraded my DSL service with MNSI.NET (Toronto, Canada) provider where they provide 6 static IP addresses (1 for router + 5 for other machines). My plan is to run 4 Windows 2003 Standard Edition webservers (4 different computers). Problem is that I have no idea how to setup and configure my Linksys WRT54GS router. This is my setup: - DSL modem plugged into Linksys router - 4 cables out from router to my 4 computers. - 1 ip address I've got from my provider to be used for router (216.x.xxx.184) and 5 others (216.x.xxx.185-190) for my webserver computers. How do I setup my DSL router to assigns these static ip addresses to my server computers? Currently, my router is setup as PPPoE and I am logging to my provider using a name and password. I use DHCP to assign ip addresses to my computers. Using this setting my router assigned different local ip addresses to each server, but no matter from which server I access www.whatismyipaddress.com (service to find ip displayed to outside world), it shows the same ip address for all server: 216.x.xxx.185. What do I have to do? Any help would be greatly appreciated. Cheers, Enzo | |||||||||||||
|
Posted by Some One on September 21, 2005, 4:47 pm
Please log in for more thread options joe@doprocess.com wrote in news:1127322729.472743.31940 @g47g2000cwa.googlegroups.com: I'm not 100% sure but I think you need to manually assign the IP address and subnet mask (and maybe DNS addresses) to each computer and then put each computer into the DMZ on your router. At that point your router is just acting as a switch. Also turn off DHCP on the router. | |||||||||||||
|
Posted by David Ross on September 22, 2005, 8:49 am
Please log in for more thread options
joe@doprocess.com wrote: > I have a quick question as a newbie about networking, that I was hoping
> someone might be able to help out with. > > I have recently upgraded my DSL service with MNSI.NET (Toronto, Canada) > provider where they provide 6 static IP addresses (1 for router + 5 for > other machines). > > My plan is to run 4 Windows 2003 Standard Edition webservers (4 > different computers). > > Problem is that I have no idea how to setup and configure my Linksys > WRT54GS router. You may not be able to. I haven't read the docs on this router but Linksys is a consumer brand and I've yet to see a consumer router support multiple static IP setups. But I may be wrong. | |||||||||||||
|
Posted by David Schwartz on September 22, 2005, 12:12 pm
Please log in for more thread options
> Using this setting my router assigned different local ip addresses to
> each server, but no matter from which server I access > www.whatismyipaddress.com (service to find ip displayed to outside > world), it shows the same ip address for all server: 216.x.xxx.185. > > What do I have to do? Turn off NAT. DS | |||||||||||||
|
Posted by Bill on September 24, 2005, 11:55 am
Please log in for more thread options
LOL...4 web servers on 1 DSL connect with an upload of what? 800k? Don't expect too much traffic. Your web servers will be like connecting to dial-up. Dump the residential class rotuer, it' won't handle it. Get a switch and put the 4 <cough> web servers on the switch and do the PPPoe on each server to
get the 1 of 6 statics directly on the systems.
Good Luck Bill >I have a quick question as a newbie about networking, that I was hoping
> someone might be able to help out with. > > I have recently upgraded my DSL service with MNSI.NET (Toronto, Canada) > provider where they provide 6 static IP addresses (1 for router + 5 for > other machines). > > My plan is to run 4 Windows 2003 Standard Edition webservers (4 > different computers). > > Problem is that I have no idea how to setup and configure my Linksys > WRT54GS router. > > This is my setup: > - DSL modem plugged into Linksys router > - 4 cables out from router to my 4 computers. > - 1 ip address I've got from my provider to be used for router > (216.x.xxx.184) and 5 others (216.x.xxx.185-190) for my webserver > computers. > > How do I setup my DSL router to assigns these static ip addresses to my > server computers? > > Currently, my router is setup as PPPoE and I am logging to my provider > using a name and password. > I use DHCP to assign ip addresses to my computers. > > Using this setting my router assigned different local ip addresses to > each server, but no matter from which server I access > www.whatismyipaddress.com (service to find ip displayed to outside > world), it shows the same ip address for all server: 216.x.xxx.185. > > What do I have to do? > > > Any help would be greatly appreciated. > > Cheers, > > Enzo > | |||||||||||||
> someone might be able to help out with.
>
> I have recently upgraded my DSL service with MNSI.NET (Toronto, Canada)
> provider where they provide 6 static IP addresses (1 for router + 5 for
> other machines).
>
> My plan is to run 4 Windows 2003 Standard Edition webservers (4
> different computers).
>
> Problem is that I have no idea how to setup and configure my Linksys
> WRT54GS router.
>
> This is my setup:
> - DSL modem plugged into Linksys router
> - 4 cables out from router to my 4 computers.
> - 1 ip address I've got from my provider to be used for router
> (216.x.xxx.184) and 5 others (216.x.xxx.185-190) for my webserver
> computers.
>
> How do I setup my DSL router to assigns these static ip addresses to my
> server computers?
>
> Currently, my router is setup as PPPoE and I am logging to my provider
> using a name and password.
> I use DHCP to assign ip addresses to my computers.
>
> Using this setting my router assigned different local ip addresses to
> each server, but no matter from which server I access
> www.whatismyipaddress.com (service to find ip displayed to outside
> world), it shows the same ip address for all server: 216.x.xxx.185.
>
> What do I have to do?
>
>
> Any help would be greatly appreciated.
>
> Cheers,
>
> Enzo
>
>
