Zigbee detection?

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View


How can I detect Zigbee radios to determine if they are interfering with my
802.11 signal...

http://en.wikipedia.org/wiki/ZigBee
Zigbee radios are used to detect water leaks, termites or similar systems in
large buildings etc...

Is there a Linux/Win32 tool that can detect them? Do they sent packets like
802.11 does?

Thanks,

Jixter



Re: Zigbee detection?



Quoted text here. Click to load it

Spectrum analyzer.  The problem is that Zigbee is frequency hopping
spread spectrum, which is not compatible with 802.11 direct sequence
spread spectrum.  Therefore, none off the common 802.11 tools will see
a Zigbee radio.

Quoted text here. Click to load it

Note that they're usually very low power.

Quoted text here. Click to load it

Zigbee is usually setup as a mesh networks.  They send and receive
lots of packets.

Possible sources of 2.4GHz interference:
  http://wireless.wikia.com/wiki/Wi-Fi#Interference

See:
  http://www.metageek.net
for the cheapest spectrum analyzer.  I have one but have never tried
it with Zigbee.  Some "recordings" of different types of non-802.11
xmitters:
  http://recordings.metageek.net/index.php
Unfortunately.  No zigbee recordings.  The Wi-Spy device is not
terribly sensitive without an external antenna.  I threw together this
antenna, which helps, but is far from optimum:
  http://www.metageek.net/forum/viewtopic.php?t=27


--
Jeff Liebermann     jeffl@comix.santa-cruz.ca.us
150 Felker St #D    http://www.LearnByDestroying.com
Santa Cruz CA 95060 http://802.11junk.com
Skype: JeffLiebermann     AE6KS    831-336-2558
