Raspberry Pi ZeroW as a WiFi Router

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View
Has anyone used a Raspberry Pi ZeroW (or another Pi, plus a USB WiFi
adapter) as a WiFi router?

As my existing WiFi router already connects to the internet using a
USB mobile broadband modem, this might suit me more than most people,
but there is an OpenWrt image for the Raspbery Pi:
https://openwrt.org/toh/raspberry_pi_foundation/raspberry_pi

My cause for looking down this path is that I want to set up a HTTPS
to HTTP proxy on the router to serve all HTTPS connections to
computers on my local network via unencrypted HTTP. This is because
all the stupid websites forcing HTTPS (when it isn't needed) are
making it difficult to keep all the software on my various computers
compatible with the various and ever-changing encryption protocols
required.

Currently I'm using a Netgear DGN2200 router, with OpenWrt installed.
However for starters there insn't enough Flash storage space (8MB) to
install all the software required to run the proxy, and beyond that
it's doubtful that the 32MB RAM and 300MHz CPU would be able to
do the job without slowing everything down.
https://openwrt.org/toh/netgear/dgn2200

The Raspberry Pi ZeroW with a 1GHz CPU and 512MB RAM should be fast
enough, and as I'm only using WiFi and USB in the existing router,
it should have all the hardware that I need built in. It would use
less power as well.

The main thing that I'm worried about though is the WiFi range. I
should be able to solder on a connector for an external antenna
as described here:
https://www.briandorey.com/post/raspberry-pi-zero-w-external-antenna-mod

However looking deeper it seems that my existing router may have
more transmitting power (28.11dBm) than the Pi ZeroW (17.0dBm).

I don't really want a significant drop in my WiFi range, so would
it be better to use a Pi Zero (non-W) and a USB WiFi adapter? In
which case, which WiFi adapters should I look for to suit this
application?

Years ago I compared the WiFi transmitting power specifications from
FCC tests for various different WiFi routers in order to get an idea
of what's "good". As noted above, the Pi ZeroW compares poorly to
the router that I chose before based on this comparison. However I'm
not sure if I might be failing to consider other important figures
from the tests (besides the antenna, which will be changed for the Pi
ZeroW).

In case it helps, or to satisfy any curiosity, here is the list
of router transmitting power with the Pi ZeroW added:

Raspberry Pi ZeroW
 -17.0dBm maximum WiFi (any channel/standard)
 -2017

Netgear DGN2200
 -28.11dBm on chn. 6 802.11g, 22.56dBm on chn. 6 802.11b
 -Two antennas
 -2010

Linksys WAP200
 -18.51dBm on chn. 6 802.11g, 16.55dBm on chn. 6 802.11
 -2007

D-Link DIR300 A1
 -24.98dBm chn. 11 802.11b, 23.19dBm chn. 11 802.11g
 -2007

Billion BiPAC 7300G
 -21.07dBm chn. 6 802.11b, 15.14dBm chn. 6 802.11g
 -2007

Motorola SBG900i
 -16.05dBm chn. 1 802.11b
 -2003

Apple AirPort Extreme A1034
 -18.4dBm chn. 11 802.11b?
 -2003

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
Computer Nerd Kev wrote:

Quoted text here. Click to load it

FWIW I suspect you'll cause yourself more grief trying to strip TLS from
all traffic than having to cope with (what should be) a tiny number of
b0rked TLS problems ...


Re: Raspberry Pi ZeroW as a WiFi Router
On 14/04/2019 04:16, Computer Nerd Kev wrote:
Quoted text here. Click to load it

Yes, I do it with the standard Stretch Raspbian on a PiZeroW and a PiB+
plus USB wifi dongle.


Quoted text here. Click to load it

Wow.. madness. Just keep your shit up to date.



Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Great, any observations comparing the Pi ZeroW with the Pi B+'s WiFi
dongle, or a normal WiFi router?

Quoted text here. Click to load it

That would mean picking up development of at least one application
which I have not found a good maintained equivalent for, plus
keeping one thing up to date will always be easier than keeping
everything up to date.

Anyway, it's a road that I want to go down having already got plenty
fed up with trying to keep things that don't deal in secure
information SSL compatible. If it's a dead end, I'm willing to find
out the hard way.

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
On 4/13/19 9:16 PM, Computer Nerd Kev wrote:
Quoted text here. Click to load it

I have not personally done so.  I know (of) some people (1 or two
degrees removed) that have done so.  The general consensus seems to be
1) that it will function and 2) that the wireless radio on the Pi has a
tendency to burn out (or otherwise be under powered) for use in an
Access Point.  They resoundingly recommend the little USB dongle that is
an AP with a small rubber duck antenna.

I've heard of this type of config being used for a LOT of things, not
just AP use cases.  (Sniffers, intrusion detection, reconnaissance, etc.)

Quoted text here. Click to load it

My biggest concern would be the bandwidth and any constraint /
contention for the USB bus.

Quoted text here. Click to load it

I've pontificated the same or a slight variation on the theme.  My use
case is for newer clients to connect to older servers that can't be
updated.  It sounds like you're primarily worried about older clients
that can't step up to the new standards.

sslstrip comes to mind.  I've not used it before.  Check it out.

I'd also consider Squid as it supports bump-in-the-wire SSL
interception.  (You need to put a cert in client device's trusted Root
CAs, but that shouldn't be a problem for you.)

I'd think you could configure Squid to strip HTTPS and / or provide a
consistent maintainable HTTPS / TLS / SSL that your devices can support
while it can step up to talk to what ever level of security on the
outside.  Plus, it can cache things for you.  ;-)

I'm sure that there are other options.  That's jut what jump out at the
moment.

Quoted text here. Click to load it

You have your opinion, and I have mine.  I see no reason to debate which
is correct.

Feel free to ask questions if you want to have a technical discussion
(with as few opinions as possible).

Quoted text here. Click to load it

I get the impression that a Pi Zero W might not be the best choice.  But
that a regular Pi might be acceptable.  Or some comparable SBC.

Quoted text here. Click to load it

Intriguing.

I don't know if or how it would effect the burnout that I was mentioning
above.

I've got to say, I would take a look at some of the GL-iNet's small
router / AP boards.  I think they've got some close to regular Pi
prices, run OpenWRT, have external antennas, and can be powered via
Power over Ethernet.

Quoted text here. Click to load it

Remember, Tx power is not all that it's cracked up to be.  Sometimes you
get better overall service with more lower power devices than fewer
higher power devices.

Quoted text here. Click to load it

I think I would use the USB WiFi adapter in favor of the WiFi adapter
built into the Pi Zero.

Quoted text here. Click to load it

Interesting data.  Thank you for sharing.



--
Grant. . . .
unix || die

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Thanks, I didn't think there would be a risk of it actually burning
out. That would be no good.

Quoted text here. Click to load it

When you say "the", does that suggest a specific model?

Quoted text here. Click to load it

That's a good point. Currently I'm only getting a maximum download
speed under 300KBytes/s via mobile broadband, and I don't do that
much bulk data transfer on the local network. I do want to move from
3G to 4G though.

Quoted text here. Click to load it

Yes, old clients that web servers won't talk to are my only worry.

Quoted text here. Click to load it

Thanks, I'll look into that.
https://moxie.org/software/sslstrip/

Quoted text here. Click to load it

Gah, I actually searched for "squid" and almost clicked the Wikipedia
page about the things with "large eyes, eight arms and two
tentacles". :)

Ah, this looks better:
http://www.squid-cache.org/

Quoted text here. Click to load it

Interesting, that does seem a bit more elegant, though I'm not really
concerned about anyone tapping into my local network traffic (even if
they crack my WiFi, they'd have to be on my property in order to get
close enough to pick up the signal).

Quoted text here. Click to load it

Alright I let myself go a little bit, but the first ten responses if
I say that I want to do x in order to strip HTTPS wouldn't be about
x, but would be asking why I want to strip HTTPS.

Quoted text here. Click to load it

I'm following you with the WiFi burn-out issue. But otherwise, I know
that a 1GHz Pentium III is plenty powerful enough to handle the SSL,
so a 1GHz Pi Zero should be powerful enough as well. So even if I
don't use the Pi ZeroW's WiFi, I don't see a need to put more
electricity and money into a faster Pi.

Quoted text here. Click to load it

OK, will do. Though the key thing is the CPU power and RAM, otherwise
I could just stick with my DGN2200 for this HTTPS to HTTP proxy (the
lower electricity usage is just a bonus from using the Pi).

Quoted text here. Click to load it

Umm, well I was hoping to keep to just one device in place of the
existing router, which is doing the job fine on its own. I know the
cost of a Pi ZeroW isn't much, but I would prefer less to configure
and less to go wrong.

Quoted text here. Click to load it

Thanks. To me that's suggesting a Pi Zero (non-W) with a USB WiFi
adapter yet to be determined. I'll have a look at what's available
for them.

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Just a tangential point...

Don?t forget that a highly directional (dish) antenna can be used to
eavesdrop or participate in a wireless LAN that is far too distant for use
by a typical low gain antenna.

--
-michael - NadaNet 3.1 and AppleCrate II:  http://michaeljmahon.com

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

That was counting anyone with a highly directional antenna. :)

I looked into using cantenna designs to connect distant buildings
via WiFi once - you'd need one at both ends in order to have some
sort of hope. Plus anyone parked by the road for any period of time
out here would be highly suspicous even before you put a big dish
on the roof into the picture. Other houses are at kilometer distances
away.

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

It works well for light traffic.

Quoted text here. Click to load it

How many devices?  The Pi0 can handle ten or so gamers concurrently
fetching small text files but two or three downloading graphics makes it
sweat...

Quoted text here. Click to load it

Proxying tends to eat memory - and if you start swapping to external storage
you'll impinge bandwith.

Quoted text here. Click to load it

You might need the bigger pi just for the memory.

Quoted text here. Click to load it

The low power Wifi is a big plus.

Quoted text here. Click to load it

A a general rule the more powerful the wifi signal the slower the transfer
as high power devices are in range of a greater number of competitors for
the channels - so they have to back-off more.  One powerful device can slow
an entire neighborhood including itself.

Aim for the signal to -just- cover the area you need and no more.

Quoted text here. Click to load it

Better to have two or three strategically placed low power (Pi?) APs on
wired connections; never use WiFi extenders, each one you add halves
throughput.

Cheerio,

--
Quoted text here. Click to load it


Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

It's just me, so two at most (if I leave something downloadling /
updating while I'm using my laptop, or am transferring between
computers). Though the 3G (soon to be 4G) mobile broadband modem
is on the USB bus as well, I don't know if that would be worse for
performance than the Ethernet adapter. I'm guessing that it's
unlikely to be a problem though - and I usually don't do any form of
streaming.

Quoted text here. Click to load it

Hmm, and swapping to Flash memory on the Pi's SD card wouldn't be ideal
for longevity either.

Quoted text here. Click to load it

Given the price, it might make sense to try it with the Pi Zero
first. If it works, it will use less power as well, if it doesn't,
then I haven't wasted much money on the Pi Zero anyway.

Quoted text here. Click to load it

Ah well, there are no other WiFi networks in range out here in the
middle of nowhere so I can pump out all the WiFi power that I can
get. :) - Some compensation for all the struggle to pick up mobile
broadband signal...

Quoted text here. Click to load it

The existing set-up proves that I don't need to do that, so I'd
prefer to stick with a single unit and have less to go wrong, update,
etc.

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
On 14/04/2019 04:16, Computer Nerd Kev wrote:
Quoted text here. Click to load it

It would be fine for one or two clients in a small area, but it's WiFi
and processing power isn't up handling a home full of devices.

[Snip list of routers]

Get yourself a decent router, I recommend ASUS, got a RT-ac68U which is
superb. It's a fibre router, but I did have to use with USB 4G dongles
for a month after moving house.

---druck


Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

My home = one or two clients at any one time. Only PCs.

Quoted text here. Click to load it

That router has half the RAM of the Pi Zero and a lower CPU clock
(though two cores instead of one). I'm sure it's fine for doing the
current job of my DGN2200, but I wouldn't consider changing that if
it wasn't for the need to run the HTTPS to HTTP software, and hence
I started looking outside the range of available routers.

https://openwrt.org/toh/asus/rt-ac68u

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
On Wed, 17 Apr 2019 00:01:43 +0000 (UTC), not@telling.you.invalid (Computer
Nerd Kev) declaimed the following:

Quoted text here. Click to load it

    You might be surprised... My primary TV and satellite box, cell-phone,
four Nooks, a couple of R-Pi 3B, Wii-U (and an older Wii once I get it back
from my father's stored junk) are all WiFi clients (the cell-phone actually
routes data connections over the WiFi in preference to GSM) -- I hardwire
the laptop and main computer, but both have WiFi client capability.
Fortunately my three Blu-Ray players were explicitly purchased without WiFi
-- and I'm not going to run CAT-5/6 to the rooms with the TVs/BD players.


--
    Wulfraed                 Dennis Lee Bieber         AF6VN
    wlfraed@ix.netcom.com

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Yeah I know, and then there are the IOT devices. In my case though I
really do just have the PCs. I often take the remarkable decision to
fix things instead of replace them, which keeps my technology
stagnant in the first place, and I don't bother with Smartphones or
Smart TVs.

Hence the trouble with HTTPS in the first place. If I have a working
system that doesn't need to communicate securly, I want to keep using
it as-is. I don't want to upgrade this, which means upgrading that,
which means changing this, which means buying a new that, and so
on...

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
On 4/18/19 5:12 PM, Computer Nerd Kev wrote:
Quoted text here. Click to load it

You can configure Apache httpd as a reverse proxy for sites and leverage
it's ability to modify HTML as it passes through.  So you can bust HTTPS
sites down to HTTP.

I'm guessing that this is much of what sslstrip does.



--
Grant. . . .
unix || die

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Thanks, my first option will be to try the No-HTTPS Perl script
which was posted in alt.sources late last year. I had a go at setting
this up on the existing router, but I soon ran out of Flash while
installing dependancies for Perl and decided that the odds of it
having enough RAM and CPU speed to do the job weren't high enough to
bother trying to sort something out with a USB memory stick.

A Pi ZeroW is on its way. I might see how I go with the onboard
WiFi for starters, Perhaps putting a heatsink on the WiFi chip
will help against the burn-out issues as it's presumably due to
something overheating. The router could be positioned better for
WiFi if I set up an outdoor directional antenna for the mobile
broadband modem, which I need to do anyway. the WiFi only really
has to cover a few rooms (though one has some metal cladding in
the way).

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
Computer Nerd Kev wrote, on 20-04-2019 03:32:
Quoted text here. Click to load it

I saw that earlier in the thread but that seemed like bullshit where
they manually tried to boost the power to the wifi chip, maybe removing
a resistor somewhere or otherwise cranking up the voltage, I don't know.
Don't do that, obviously.

Bandwidth will be the issue, wifi up & down on all channels (uplink,
clients) going over 1 shared USB2 connection, including storage traffic
if you want something a little more reliable than an sd card. Maybe you
figured out it will suffice in your situation but I fear for the
practical result.

Of course, putting this all together won't be a one time job, you'll
have to maintain it and that would ultimately put me off; you're just
shifting the work to a dead end.

Fine for a "can it be done" hobby project.

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

I do plan to add an external antenna. With RF anything is possible,
but in theory I don't think that should increase the risk, and if the
Pi needs to use less power or do fewer retransmissions, that may help
prevent overheating in relative terms.

Quoted text here. Click to load it

Well I know that this is simplifying things, but I currently get
< 300KBytes/s speed with 3G mobile broadband (poor reception, I do
hope to increase that with 4G and the better antenna, but I do
alright with it). USB2 can in theory manage 60MBytes/s, so if you
have 300KBytes going in to the Pi from the modem (granted there will
be some extra handshaking data going to/from the modem as well, but
presumably not that much), then there's a lot of bandwidth still
there for getting the data to the WiFi interface.

Quoted text here. Click to load it

Using OpenWRT (which I am already) at least means that if something
breaks after an update, there should be clear instructions on how to
get it working as a router again. On the update side of things the Pi
is a big advantage as well, because currently updating the OpenWRT
firmware requires wiring up the serial port via a level converter,
remembering how to start/configure the tftp server software (my
traditional stumbling point) while the router is connected to a PC
via an ethernet cable (NOT a broken one - kept me confused for quite
a while last time), then hoping that it doesn't get interrupted
mid-way and brick the thing (which is why I especially like having
the spare (actually spares)).

For the Pi I can just write an SD card image, and keep an old card
with the previous install in case it doesn't work. Heaven!

Granted there may be easier processes with some other routers (though
the ones that I found when choosing last time were mostly harder).

That said, using OpenWRT means that configuring my HTTP - HTTPS proxy
will be a lot harder. Still much easier than trying to keep all of my
preferred software and hardware compatible with HTTPS though.

--
__          __
#_ < |\| |< _#

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

An impedance mismatch between the RF chip and the antenna can cause
significant impact to the power dissipated by the chip. (And mismatches are
pretty easy to get at 2.4GHz.)

--
-michael - NadaNet 3.1 and AppleCrate II:  http://michaeljmahon.com

Re: Raspberry Pi ZeroW as a WiFi Router
Quoted text here. Click to load it

Well I was going to pull a WiFi antenna out of another old router.
Are they all likely to be close enough, or should I look into the
figures properly?

I've hapily connected any convenient WiFi antenna to PCI WiFi cards
in the past without concern for impedance differences, and got away
with it so far.

--
__          __
#_ < |\| |< _#

Site Timeline
