Why can't a VPN ovpn file set everything that needs to be set?


http://i60.tinypic.com/ubg9v.jpg

What do I need to do to get a simple ovpn file to set up a
vpn in NetworkManager in a single file load, including the connection
type, ca file, username and password *without* having to manually
edit the connection type, ca file location, username, & password?

Why can't the file load just set everything that needs to be set?

Here's what I do now (but it takes multiple steps which I don't
understand why). [All I want is for the loaded file to set up itself.]

0. At mofolinux, I press on the openvpn list to choose an ovpn file:
   http://mofolinux.com/vpngate.html

1. I save any of those files to /tmp with the default file name:
   /tmp/vpngate_vpn326801121.opengw.net_udp_1195.ovpn

2. I hit the setup wrench in the Kubuntu KDE NetworkManager and then
   I hit "File > Import VPN" and point to the file above.

http://i60.tinypic.com/ubg9v.jpg

3. This is *supposed* to set up the VPN connection; but it does not.
   I still have to perform the following (which shouldn't be necessary).
    Connection Type
    CA File
    Username
    Password

Can't an openvpn ovpn file simply set up the connection type, ca file,
username & password?
http://i60.tinypic.com/ubg9v.jpg

Why can't a VPN ovpn file set everything that needs to be set?

Re: Why can't a VPN ovpn file set everything that needs to be set?
Maraela J. wrote:

Quoted text here. Click to load it

I tried appending the file but the angle brackets won't let it post,
so, I changed all the open angle brackets (<) to the keystring "123"
and I changed all the close angle brackets (>) to the keystring "456".

Q: Why doesn't this file set the connection type, CA file, login,
and password?

###############################################################################
# OpenVPN 2.0 Sample Configuration File
# for PacketiX VPN / SoftEther VPN Server
#
# !!! AUTO-GENERATED BY SOFTETHER VPN SERVER MANAGEMENT TOOL !!!
#
# !!! YOU HAVE TO REVIEW IT BEFORE USE AND MODIFY IT AS NECESSARY !!!
#
# This configuration file is auto-generated. You might use this config
file
# in order to connect to the PacketiX VPN / SoftEther VPN Server.
# However, before you try it, you should review the descriptions of the
file
# to determine the necessity to modify to suitable for your real
environment.
# If necessary, you have to modify a little adequately on the file.
# For example, the IP address or the hostname as a destination VPN Server
# should be confirmed.
#
# Note that to use OpenVPN 2.0, you have to put the certification file of
# the destination VPN Server on the OpenVPN Client computer when you use
this
# config file. Please refer the below descriptions carefully.


###############################################################################
# Specify the type of the layer of the VPN connection.
#
# To connect to the VPN Server as a "Remote-Access VPN Client PC",
#  specify 'dev tun'. (Layer-3 IP Routing Mode)
#
# To connect to the VPN Server as a bridging equipment of "Site-to-Site
VPN",
#  specify 'dev tap'. (Layer-2 Ethernet Bridgine Mode)

dev tun


###############################################################################
# Specify the underlying protocol beyond the Internet.
# Note that this setting must be correspond with the listening setting on
# the VPN Server.
#
# Specify either 'proto tcp' or 'proto udp'.

proto udp


###############################################################################
# The destination hostname / IP address, and port number of
# the target VPN Server.
#
# You have to specify as 'remote 123HOSTNAME456 123PORT456'. You can also
# specify the IP address instead of the hostname.
#
# Note that the auto-generated below hostname are a "auto-detected
# IP address" of the VPN Server. You have to confirm the correctness
# beforehand.
#
# When you want to connect to the VPN Server by using TCP protocol,
# the port number of the destination TCP port should be same as one of
# the available TCP listeners on the VPN Server.
#
# When you use UDP protocol, the port number must same as the
configuration
# setting of "OpenVPN Server Compatible Function" on the VPN Server.

remote vpn326801121.opengw.net 1195


###############################################################################
# The HTTP/HTTPS proxy setting.
#
# Only if you have to use the Internet via a proxy, uncomment the below
# two lines and specify the proxy address and the port number.
# In the case of using proxy-authentication, refer the OpenVPN manual.

;http-proxy-retry
;http-proxy [proxy server] [proxy port]


###############################################################################
# The encryption and authentication algorithm.
#
# Default setting is good. Modify it as you prefer.
# When you specify an unsupported algorithm, the error will occur.
#
# The supported algorithms are as follows:
#  cipher: [NULL-CIPHER] NULL AES-128-CBC AES-192-CBC AES-256-CBC BF-CBC
#          CAST-CBC CAST5-CBC DES-CBC DES-EDE-CBC DES-EDE3-CBC DESX-CBC
#          RC2-40-CBC RC2-64-CBC RC2-CBC
#  auth:   SHA SHA1 MD5 MD4 RMD160

cipher AES-128-CBC
auth SHA1


###############################################################################
# Other parameters necessary to connect to the VPN Server.
#
# It is not recommended to modify it unless you have a particular need.

resolv-retry infinite
nobind
persist-key
persist-tun
client
verb 3
#auth-user-pass


###############################################################################
# The certificate file of the destination VPN Server.
#
# The CA certificate file is embedded in the inline format.
# You can replace this CA contents if necessary.
# Please note that if the server certificate is not a self-signed, you
have to
# specify the signer's root certificate (CA) here.

123ca456
-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----

123/ca456


###############################################################################
# The client certificate file (dummy).
#
# In some implementations of OpenVPN Client software
# (for example: OpenVPN Client for iOS),
# a pair of client certificate and private key must be included on the
# configuration file due to the limitation of the client.
# So this sample configuration file has a dummy pair of client certificate
# and private key as follows.

123cert456
-----BEGIN CERTIFICATE-----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-----END CERTIFICATE-----

123/cert456

123key456
-----BEGIN RSA PRIVATE KEY-----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-----END RSA PRIVATE KEY-----

123/key456
