Posted by Andrei Alexandrescu (See Websi on February 2, 2008, 7:28 pm
Please log in for more thread options Hope this is the right forum, if not please advise. I own a ZyXel P-660R-ELNK DSL modem connected to a Netgear WGR615V unlocked router. After some fiddling, I managed to make the whole thing work with Callcentric a few months ago, and have been quite happy since. The original settings that I believe are salient were: ZyXel ===== RIP direction: both RIP version: RIP-2B NAT mode: SUA only SIP ALG: enabled UPnP: disabled Security, filtering etc.: no special measures taken Netgear ======= SIP proxy: callcentric.com SIP control port: 5060 SIP local port: 5060 SIP message TOS Value: 68 hex Starting RTP Port: 16384 RTP Data TOS Value: b8 hex Use Outbound SIP proxy: yes Outbound SIP proxy address: callcentric.com Outbound SIP proxy port: 5060 VAD: no STUN: no Register expire time: 30 sec Registration head start time: 0 sec DNS server: yes Primary DNS: 208.67.222.222 Secondary DNS: 208.67.220.220 It all works fine. Now, yesterday I found out that callwithus.com has better rates for my calling patterns, so I signed up. My new settings were: ZyXel ===== unchanged Netgear ======= As per http://www.callwithus.com/configuration The main change from Callcentric was the use of STUN. I tried my account a number of times (with rebooting the router and the modem, the works), no avail. I wrote CallWithUs' support and they said they receive no registration attempts from my account. I hypothesized that the use of STUN somehow does not go well with the modem. Could that be the case? To confirm that, I also signed up with voicestick.com. They don't use STUN. They also are very shy about publishing their SIP client configuration. I fished one from this forum, which looks like this: ZyXel ===== unchanged Netgear ======= SIP proxy: 206.165.50.116 SIP control port: 5060 SIP local port: 5060 SIP message TOS Value: 68 hex Starting RTP Port: 16384 RTP Data TOS Value: b8 hex Use Outbound SIP proxy: yes Outbound SIP proxy address: 206.165.50.116 Outbound SIP proxy port: 5060 VAD: no STUN: no Register expire time: 30 sec Registration head start time: 0 sec DNS server: yes Primary DNS: 208.67.222.222 Secondary DNS: 208.67.220.220 However, that didn't work either! So now I'm back to my Callcentric setup which again works, and I can't understand how neither of the others work. Any insight would be appreciated. Thanks! Andrei | |||||||||||||||||||
|
Posted by Balwinder S Dheeman on February 2, 2008, 7:58 pm
Please log in for more thread options I think, your best bet is to try both the services which did not work with YATE Client (either QT4 or GTK2 version, see http://YATE.null.ro/). Run this soft-phone from command prompt or a xterm in a verbose/bebug mode and figure out the problem by looking at the messages. Hope that helps. -- Dr Balwinder S "bsd" Dheeman Registered Linux User: #229709 Anu'z Linux@HOME (Unix Shoppe) Machines: #168573, 170593, 259192 Chandigarh, UT, 160062, India Gentoo, Fedora, Debian/FreeBSD/XP Home: http://cto.homelinux.net/~bsd/ Visit: http://counter.li.org/ | |||||||||||||||||||
|
Posted by Andrei Alexandrescu (See Websi on February 2, 2008, 8:30 pm
Please log in for more thread options Balwinder S Dheeman wrote:
> I think, your best bet is to try both the services which did not work
> with YATE Client (either QT4 or GTK2 version, see http://YATE.null.ro/). > Run this soft-phone from command prompt or a xterm in a verbose/bebug > mode and figure out the problem by looking at the messages. > > Hope that helps. Thanks Balwinder, this software looks quite what the doctor prescribed; my router has no debugging ability. Incidentally I'm originally Romanian :o). Andrei | |||||||||||||||||||
| Similar Threads | Posted |
| SIP client setup for callcentric, callwithus, and voicestick | February 2, 2008, 7:28 pm |
| VoiceStick? | October 13, 2005, 7:01 pm |
| voicestick | November 25, 2005, 12:05 pm |
| VoiceStick I2Bridge service - how good, or bad?? | May 24, 2006, 1:54 pm |
| Is VoiceStick still offering Free DIDs? | January 17, 2007, 11:29 am |
| SIP FAX CLIENT FOR WINDOWS ? | January 27, 2005, 11:50 pm |
| H323 client | March 3, 2005, 11:03 pm |
| Setting up SIP client questions (on Mac OS X) | September 24, 2005, 10:44 pm |
| ASTERISK, wrong client rings!!! | October 17, 2005, 12:11 am |
| Looking for Embedded Linux open source SIP Client | August 15, 2006, 12:55 pm |
| Client-side mixing for VOIP conferences | September 21, 2006, 6:51 pm |
| VoIP client for Windows that can record conversations? | December 7, 2006, 4:18 pm |
| Open source implementation of STUN client/server? | July 16, 2004, 5:52 am |
| Blue Digits LLC releases VM Rover - Universal Voicemail Client | August 5, 2004, 7:39 pm |
| How to setup | February 16, 2008, 5:34 am |
>
> I own a ZyXel P-660R-ELNK DSL modem connected to a Netgear WGR615V
> unlocked router. After some fiddling, I managed to make the whole thing
> work with Callcentric a few months ago, and have been quite happy since.
> The original settings that I believe are salient were:
>
> ZyXel
> =====
> RIP direction: both
> RIP version: RIP-2B
> NAT mode: SUA only
> SIP ALG: enabled
> UPnP: disabled
> Security, filtering etc.: no special measures taken
>
> Netgear
> =======
> SIP proxy: callcentric.com
> SIP control port: 5060
> SIP local port: 5060
> SIP message TOS Value: 68 hex
> Starting RTP Port: 16384
> RTP Data TOS Value: b8 hex
> Use Outbound SIP proxy: yes
> Outbound SIP proxy address: callcentric.com
> Outbound SIP proxy port: 5060
> VAD: no
> STUN: no
> Register expire time: 30 sec
> Registration head start time: 0 sec
> DNS server: yes
> Primary DNS: 208.67.222.222
> Secondary DNS: 208.67.220.220
>
> It all works fine. Now, yesterday I found out that callwithus.com has
> better rates for my calling patterns, so I signed up. My new settings were:
>
> ZyXel
> =====
> unchanged
>
> Netgear
> =======
> As per http://www.callwithus.com/configuration
>
> The main change from Callcentric was the use of STUN. I tried my account
> a number of times (with rebooting the router and the modem, the works),
> no avail. I wrote CallWithUs' support and they said they receive no
> registration attempts from my account.
>
> I hypothesized that the use of STUN somehow does not go well with the
> modem. Could that be the case? To confirm that, I also signed up with
> voicestick.com. They don't use STUN. They also are very shy about
> publishing their SIP client configuration. I fished one from this forum,
> which looks like this:
>
> ZyXel
> =====
> unchanged
>
> Netgear
> =======
> SIP proxy: 206.165.50.116
> SIP control port: 5060
> SIP local port: 5060
> SIP message TOS Value: 68 hex
> Starting RTP Port: 16384
> RTP Data TOS Value: b8 hex
> Use Outbound SIP proxy: yes
> Outbound SIP proxy address: 206.165.50.116
> Outbound SIP proxy port: 5060
> VAD: no
> STUN: no
> Register expire time: 30 sec
> Registration head start time: 0 sec
> DNS server: yes
> Primary DNS: 208.67.222.222
> Secondary DNS: 208.67.220.220
>
> However, that didn't work either! So now I'm back to my Callcentric
> setup which again works, and I can't understand how neither of the
> others work. Any insight would be appreciated. Thanks!
