Posted by peasngrits on August 8, 2006, 10:49 am
Please log in for more thread options Hello, Does anyone know if there is a box available to allow me to join both my telco single line and my vonage line together in one box. I'm in the Bahamas. I would like to be able to call in from my cell or other landline and enter some type of code or function that then allows me to receive a dial tone from my vonage box and make a call. Similar to a pbx I guess, but with only two lines. My Vonage box is the Cisco ATA-186. So I would go from my vonage box into the " new switch box or something" with a phone line, and my telco line would also go into the "new switch box or something". Thanks. I don't know if this is something that can be done with Asterisk, a linux box and two regular modems, but can someone confirm that please? -- -- +----------------------------------------------------------+ | http://forums.cabling-design.com/ | | *** a better way to USENET *** | | no-spam Web and RSS interface to your favorite newsgroup | | comp.dcom.telecom.tech - 3849 messages and counting! | +----------------------------------------------------------+ | ||||||||||||||||||||||||||||
|
Posted by Ray Cassick \(Home\) on August 8, 2006, 11:38 pm
Please log in for more thread options Yes Asterisk can be used to do this. Get a Sipura FXS/FXO box and attach your Vonage line to the in on that box and then the out of that box to a real land line then set up your dial plan in Asterisk to do what you want. | ||||||||||||||||||||||||||||
|
Posted by peasngrits on August 9, 2006, 10:21 am
Please log in for more thread options
So you're saying that I need to use both the Sipura box and Asterisk? I would have thought it would be one or the other. I have to read up on Asterisk some more, but how would the asterisk box be connected to the sipura box? Would asterisk then be controlling the sipura box as a switch? Ray Cassick \(Home\) wrote: > Yes Asterisk can be used to do this.
> Get a Sipura FXS/FXO box and attach your Vonage line to the in on that
> box > and then the out of that box to a real land line then set up your dial > plan > in Asterisk to do what you want. > wrote in message
>> Hello,
>> Does anyone know if there is a box available to allow me to join >> both my >> telco single line and my vonage line together in one box. I'm in >> the >> Bahamas. I would like to be able to call in from my cell or other >> landline >> and enter some type of code or function that then allows me to >> receive a >> dial tone from my vonage box and make a call. Similar to a pbx I >> guess, >> but with only two lines. My Vonage box is the Cisco ATA-186. >> So I would go from my vonage box into the " new switch box or >> something" >> with a phone line, and my telco line would also go into the >> "new switch >> box or something". >> >> Thanks. I don't know if this is something that can be done with >> Asterisk, >> a linux box and two regular modems, but can someone confirm that >> please? >> >> >> >> >> -- >> >> >> >> >> >> -- >> +----------------------------------------------------------+ >> | http://forums.cabling-design.com/ | >> | *** a better way to USENET *** | >> | no-spam Web and RSS interface to your favorite newsgroup | >> | comp.dcom.telecom.tech - 3849 messages and counting! | >> +----------------------------------------------------------+ >> -- -- +----------------------------------------------------------+ | http://forums.cabling-design.com/ | | *** a better way to USENET *** | | no-spam Web and RSS interface to your favorite newsgroup | | comp.dcom.telecom.tech - 3850 messages and counting! | +----------------------------------------------------------+ | ||||||||||||||||||||||||||||
|
Posted by Eugene Blanchard on August 9, 2006, 11:15 am
Please log in for more thread options
You could use one of the FXO/FXS PCI cards for the Asterisk PC instead of the Sipura box. You can get them from Digium or buy one of ebay http://www.digium.com/en/products/hardware/devkit.php The FXO goes to the telco, the FXS goes to the Vonage line. peasngrits wrote: > So you're saying that I need to use both the Sipura box and Asterisk? I
> would have thought it would be one or the other. > I have to read up on Asterisk some more, but how would the asterisk box be > connected to the sipura box? Would asterisk then be controlling the sipura > box as a switch? > > > > > Ray Cassick \(Home\) wrote: > >> Yes Asterisk can be used to do this.
>
>> Get a Sipura FXS/FXO box and attach your Vonage line to the in on that
>> box >> and then the out of that box to a real land line then set up your dial >> plan >> in Asterisk to do what you want. >
>> wrote in message
>>> Hello,
>>> Does anyone know if there is a box available to allow me to join >>> both my >>> telco single line and my vonage line together in one box. I'm in >>> the >>> Bahamas. I would like to be able to call in from my cell or other >>> landline >>> and enter some type of code or function that then allows me to >>> receive a >>> dial tone from my vonage box and make a call. Similar to a pbx I >>> guess, >>> but with only two lines. My Vonage box is the Cisco ATA-186. >>> So I would go from my vonage box into the " new switch box or >>> something" >>> with a phone line, and my telco line would also go into the >>> "new switch >>> box or something". >>> >>> Thanks. I don't know if this is something that can be done with >>> Asterisk, >>> a linux box and two regular modems, but can someone confirm that >>> please? >>> >>> >>> >>> >>> -- >>> >>> >>> >>> >>> >>> -- >>> +----------------------------------------------------------+ >>> | http://forums.cabling-design.com/ | >>> | *** a better way to USENET *** | >>> | no-spam Web and RSS interface to your favorite newsgroup | >>> | comp.dcom.telecom.tech - 3849 messages and counting! | >>> +----------------------------------------------------------+ >>> >
> > > > > -- > > > > > | ||||||||||||||||||||||||||||
|
Posted by Wolfgang S. Rupprecht on August 9, 2006, 1:16 pm
Please log in for more thread options
peasngrits_at_coralwave_dot_com@foo.com (peasngrits) writes: > So you're saying that I need to use both the Sipura box and Asterisk? I
> would have thought it would be one or the other. > I have to read up on Asterisk some more, but how would the asterisk box be > connected to the sipura box? Would asterisk then be controlling the sipura > box as a switch? The Sipura SPA-300, all by itself, will allow you to call out on POTS line from a SIP connection. Download the SPA-3000 manual from Sipura to see the full set of gatewaying functions it can do. The problem you'll find is that Vonage doesn't really let you use your own equipment. They want you to use theirs and they lock it down so you can't change anything. (BTW. I have a spa-3000 but just use it with asterisk. I did see all the standalone gatewaying functions in the manual but have never used them.) -wolfgang -- Wolfgang S. Rupprecht http://www.wsrcc.com/wolfgang/ | ||||||||||||||||||||||||||||
