I have Time/Warner digital phone service for one telephone line.

I'd like to go from the phone modem to my patch panel and distribute the
line to multiple rooms.

I had this up and running for a while, no problems.

Recently, I started losing my dialtone.  I had a service rep out a couple
of times, replaced the modem and had several "debug" discussions on the
phone with Time/Warner.

The net of all this is "Time/Warner doesn't support..." my configuration.

I assume there needs to be some boosting of the signal from the modem in
order to travel all those extra miles of CAT-5 ;-)

Any ideas how I can do this and make it reliable?

Thanks,

mitch

Re: Digital Phone Distribution

Quoted text here. Click to load it

So their argument is that they offer "home phone service", attempting to
compete with traditional analog telephone, but only to ONE HANDSET?

I didn't bother to wire this house for telephone. I use Uniden cordless
units with chargers sprinkled around the house and a single base station.
Even if you only did this for half of your phones, you might reduce the load
on the modem.



Re: Digital Phone Distribution
sumcoolgai[nospam]@yahoo.com (Mitch P.) writes:
| I have Time/Warner digital phone service for one telephone line.
|
| I'd like to go from the phone modem to my patch panel and distribute the
| line to multiple rooms.
|
| I had this up and running for a while, no problems.
|
| Recently, I started losing my dialtone.  I had a service rep out a couple
| of times, replaced the modem and had several "debug" discussions on the
| phone with Time/Warner.
|
| The net of all this is "Time/Warner doesn't support..." my configuration.
|
| I assume there needs to be some boosting of the signal from the modem in
| order to travel all those extra miles of CAT-5 ;-)
|
| Any ideas how I can do this and make it reliable?

You might try a long loop adapter which boosts the loop and ring voltages.
This one seems to always be on sale:

http://www.sjtelecommunications.com/vik-lla-1.html

There are similar products that boost only the loop voltage or only the
ring voltage.  They generally cost less.  Example:

http://www.sandman.com/loop.html#LongLoopAdapter

                Dan Lanciani
                ddl@danlan.*com
