Posted by DLC on April 9, 2007, 4:20 pm
Please log in for more thread options sine wave inverter. I want to install a light for the outhouse that is located about 100 feet from the cabin and I would like to be able to control the light from the cabin and the outhouse. X10 would be adequate if it will work with the inverter. Has anyone experience or opinions about this? Thanks, DLC | |||||||||||||||||||
|
Posted by Dave Houston on April 9, 2007, 4:59 pm
Please log in for more thread options This page suggests it will not work... http://kbase.x10.com/wiki/Pure_Sine_Wave_Inverters How do you plan to send the commands? All of the RF transceivers and manual controllers (e.g. mini/maxi-Controller) send on all three phases so they will likely fail for the reasons implied on the cited page. I suspect a transmitter that sends only on one phase might work (if the duration of the positive square wave is > 1ms) but the only transmitters that send on one
phase are PC interfaces made by Smarthome (e.g. 1132B).
Your best bet would be direct RF control. GE's Smarthome line is inexpensive but hard to find. 100' line-of-sight is probably OK. http://www.dimango.com/sa-ge-smart-home.htm http://davehouston.net http://tech.groups.yahoo.com/group/roZetta/ roZetta-subscribe@yahoogroups.com | |||||||||||||||||||
|
Posted by Dave Houston on April 9, 2007, 5:53 pm
Please log in for more thread options
>I have a small solar system for my weekend cabin that uses a modified
>sine wave inverter. > >I want to install a light for the outhouse that is located about 100 >feet from the cabin and I would like to be able to control the light >from the cabin and the outhouse. X10 would be adequate if it will work >with the inverter. > >Has anyone experience or opinions about this? > >Thanks, > >DLC Why not just use a 3-way switch configuration using standard switches? http://www.selfhelpandmore.com/switchoutlet/3way/index.htm http://davehouston.net http://tech.groups.yahoo.com/group/roZetta/ roZetta-subscribe@yahoogroups.com | |||||||||||||||||||
|
Posted by DLC on April 10, 2007, 10:07 am
Please log in for more thread options Dave Houston wrote:
>
>> I have a small solar system for my weekend cabin that uses a modified
>> sine wave inverter. >> >> I want to install a light for the outhouse that is located about 100 >> feet from the cabin and I would like to be able to control the light >>from the cabin and the outhouse. X10 would be adequate if it will work >> with the inverter. >> >> Has anyone experience or opinions about this? >> >> Thanks, >> >> DLC >
> Why not just use a 3-way switch configuration using standard switches? > > http://www.selfhelpandmore.com/switchoutlet/3way/index.htm > > > http://davehouston.net > http://tech.groups.yahoo.com/group/roZetta/ > roZetta-subscribe@yahoogroups.com Thanks for your comments. I am familiar with 3-way switches and have wired circuits with three switches. I was hoping that X-10 could be used so that I would not need to run up to 150 feet of new wire across a stream and up a hill in order to add the switch. Anyway, carrying a lattern seems more appropriate when going to an outhouse. DLC | |||||||||||||||||||
|
Posted by Gerald on April 10, 2007, 4:03 pm
Please log in for more thread options On Tue, 10 Apr 2007 14:07:19 +0000, DLC wrote:
> Dave Houston wrote:
>>
>>> I have a small solar system for my weekend cabin that uses a modified
>>> sine wave inverter. >>> >>> I want to install a light for the outhouse that is located about 100 >>> feet from the cabin and I would like to be able to control the light >>> from the cabin and the outhouse. X10 would be adequate if it will work >>> with the inverter. >>> >>> DLC
>>
>> Why not just use a 3-way switch configuration using standard switches? >> >> http://www.selfhelpandmore.com/switchoutlet/3way/index.htm >> >> >> http://davehouston.net >
> Thanks for your comments. > > I am familiar with 3-way switches and have wired circuits with three > switches. > > I was hoping that X-10 could be used so that I would not need to run up > to 150 feet of new wire across a stream and up a hill in order to add > the switch. > > Anyway, carrying a lattern seems more appropriate when going to an outhouse. > > DLC Full on X10 using the PLC part might not work but Dave's suggestion of RF hints at a solution. Just pick up an RR501 and a couple of KR22a or KR19A remotes from EBay. Then modify the RR501 a bit by 1. extending the antenna to make it a true 1/4 wave or 1/2 wave length and 2. (optional) desolder the receptacle and plug and hard wire it to your incoming power and your light (or skip this step and plug it into a receptacle in the outhouse and use a plug-in lamp for the light). You could probably poke around on Ido's website a bit and figure out how to disable the PLC xmit/rcv circuitry as well if you're worried that signals from the RR501 might cause other havoc due to the MSW-inverter. www.geocities.com/ido_bartana/ <--- as of this message unavailable due to bandwidth restriction Here's a google cache of a page from the site dealing with RF range improvements: http://72.14.209.104/search?q=cache:Vf5HGYHsNv8J:www.geocities.com/ido_bartana/modifying_remote_control_transce.htm+rr501+bartana&hl=en&ct=clnk&cd=1&gl=us&lr=lang_en Of course, before modifying anything I would just plug it in and test it to see how far away you can get and make it work. In an area with little stray RF you might not need to modify anything. Gerald -- If you need to email me directly use: junkmail sysmatrix Put the appropriate symbol in there and end it with a fish catcher. | |||||||||||||||||||
