FTP partially blocked-- how to trace?

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View
Hello,

I use various programs to  such as Ultraedit to upload files via FTP.
On one site, all of a sudden I began having a mysterious problem. I
can log onto the site, but I cannot do anything alse. I am able to get
the name of the directory I am in but I can't get any other directory
information, change directories or access any files.

I am only having this problem on one site. All my programs, smartFTP,
WSFTP, HtmlKit , NVU were effected at the same time, except WinSCP
which still works fine. The Server tech had changed some firewall
settings but has been unable to figure out what the problem is. I'm
still suspect it has something to do with the firewall settings on the
server. It only seems to effect my account, It doesn't make a
difference if I use passive or not passive, or if I take down all
firewalls on my end. I double checked that it  is not something on my
computer by using another computer, albeit from the same location. It
had the same problem.

Here is one attempt by htmlKit, in non passive mode:

HtmlKit:
FTP > PWD
FTP < 257 "/home/trt/www/html/website.com" is your current location
FTP > PORT 192,168,1,101,4,110
FTP < 500 Unknown command
FTP > 500 Unknown command
FTP - Could not get directory list. (933)
FTP > CWD /home/trt/www/html/website.com
FTP < 250 OK. Current directory is /home/bvb/www/html/website.com

Any Idea what it could be ?

I had the idea that if I could possibly see the requests that WinSCP
and UltraEdit send to the server,  I could compare them and and
possibly see what is working and what is not. If it were http traffic,
I would use Charles http://xk72.com/ an HTTP proxy / HTTP monitor.  Is
there an FTP equivilant ?

Thanks.

Red


FTP partially blocked-- how to trace?
Hello,

I use various programs to  such as Ultraedit to upload files via FTP.
On one site, all of a sudden I began having a mysterious problem. I
can log onto the site, but I cannot do anything alse. I am able to get
the name of the directory I am in but I can't get any other directory
information, change directories or access any files.

I am only having this problem on one site. All my programs, smartFTP,
WSFTP, HtmlKit , NVU were effected at the same time, except WinSCP
which still works fine. The Server tech had changed some firewall
settings but has been unable to figure out what the problem is. I'm
still suspect it has something to do with the firewall settings on the
server. It only seems to effect my account, It doesn't make a
difference if I use passive or not passive, or if I take down all
firewalls on my end. I double checked that it  is not something on my
computer by using another computer, albeit from the same location. It
had the same problem.

Here is one attempt by htmlKit, in non passive mode:

HtmlKit:
FTP > PWD
FTP < 257 "/home/trt/www/html/website.com" is your current location
FTP > PORT 192,168,1,101,4,110
FTP < 500 Unknown command
FTP > 500 Unknown command
FTP - Could not get directory list. (933)
FTP > CWD /home/trt/www/html/website.com
FTP < 250 OK. Current directory is /home/bvb/www/html/website.com

Any Idea what it could be ?

I had the idea that if I could possibly see the requests that WinSCP
and UltraEdit send to the server,  I could compare them and and
possibly see what is working and what is not. If it were http traffic,
I would use Charles http://xk72.com/ an HTTP proxy / HTTP monitor.  Is
there an FTP equivilant ?

Thanks.

Red


Re: FTP partially blocked-- how to trace?
The carbonbased lifeform red inspired comp.security.firewalls with:
Quoted text here. Click to load it

Sounds like a (Unix) permission problem.
Try 'ls -al' in that directory and see if this and other directories
have the 'x' (search bit) and 'r' (read bit) set for the user and group.

Theo
--
theo at van-werkhoven.nl    ICQ:277217131                      SuSE Linux
linuxcounter.org: 99872  Jabber:muadib at jabber.xs4all.nl  AMD XP3000+ 1024MB
"ik _heb_ niets tegen Microsoft, ik heb iets tegen
 de uitwassen *van* Microsoft"

Re: FTP partially blocked-- how to trace?
at 10:55:33 on Sun, 19 Aug 2007, Theo v. Werkhoven
Quoted text here. Click to load it
 >
The OP probably won't know what user and group are.  Permissions could
be something like rwxrwxrwx or r--r--r-- for example
The first 3 characters refer to user, the next 3 the group and the final
3 "other users"

Doesn't he want to be looking at the permissions on the directory
itself, so he needs to go up to the parent directory - possibly won't be
able to do that unless he has access to the full directory structure

Anyway, I had similar experiences to the OP when I started using
Kapersky, and I've never got to the bottom of it.
--
Mike News

Re: FTP partially blocked-- how to trace?


On Aug 19, 7:23 am, Mike
Quoted text here. Click to load it

I figured it out. Once I realized that WinSCP works because it uses a
secure protocol, it was obvious that someone must have changed
something on the server to only allow secure FTP.   When I changed the
protocol in Ultraedit from SCP to SFTP -SSH2 it fixed the problem.

As a test, I changed the protocol in WinSCP from SFTP to SCP and it
still worked. So the permission denials were not based on using SCP as
an FTP protocol - they were based on SSH

Then I changed the SSH to SSH1 and it didn't work anymore.

I'm not sure this has anything to do with SSH but the permissions of
the root folder are
rwxr-xr-x

There's one thing that still doesn't make sense though:

Other servers that I FTP to also require SSH2. If I try to log onto
them using WinSCP with SSH1, I can't even log on. But if I uncheck
SFTP -SSH2 in UltraEdit, it still works fine. I'm not sure what's
going on there.

Why does not having  SFTP -SSH2 checked work fine on one server that
requires SSH2 but not another server that also requires SSH2. I would
think the difference would be in the FTP protocol(SFTP vs SCP) but as
I said SFTP doesn't seem to be required on the same server that
requires that SFTP -SSH2 be checked.

It works well enough that I can get back to work, but its little
things like that that bug me no end.


Re: FTP partially blocked-- how to trace?


Quoted text here. Click to load it

I went to take a walk and it suddenly occurred to me that not having
SFTP -SSH2 checked doesn't mean it uses SSH1, it means there is no
SSH. No SSH is allowed, but SSH1 is not allowed. Now it makes sense!


Re: FTP partially blocked-- how to trace?
red wrote:

Quoted text here. Click to load it

Your client tries active mode and that doesn't work.

Quoted text here. Click to load it

scp or sftp uses ssh and so overcomes the common ftp protocol crap.

Quoted text here. Click to load it

The log of the ftp session shown below is quite clear.

Quoted text here. Click to load it

ftp active mode (that is what your client tries at least in the example you
gave) doesn't work.

Quoted text here. Click to load it

ftp active mode (that i what your client tried in this case) doesn't work.

If it is really correct that passive mode doesn't work either it could that
the ftp server offers ftp active mode only (I'd call that a braindead
configuration for an ftp server) and a filter in front of the server
permits ftp passive mode only. Use a sniffer like tcpdump and/or wireshark
to find out which connections are trying to be established.

http://www.troubleshootingnetworks.com/ftpinfo.html

gives you an idea about the difference between active and passive mode and
for what to look for in the log of the sniffer.

Wolfgang
