VLAN Routing

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View


I posted awhile back on another group explaining my situation. We are
trying to bring together two very large networks. So here is the
situation.

I have a church I'm trying to help out with a network topology.  They
have a school and a rectory they want to connect via fiber.

However, the school wants to continue with their outbound internet
connection and DHCP server.  The rectory also wants to continue with
their outbound internet connection and DHCP server.

Consolidation is NOT a possibility.

I'll attach the router config log and a simple diagram of our current
setup. But we've decided that we will create 2 VLANs and setup routes
between the two internally, on a single Dell Powerconnect 6224 that is
supposed to have Layer 3 routing capability.

So before deploying this. We've setup a mock network within our office
consisting of 2 Linksys WRT54G routers, 2 computers and 1 Dell
Powerconnect 6224 switch. We have setup 2 VLANs and placed 1 PC and 1
router in each VLAN and are attempting to allow the PCs to communicate
via routing through each VLAN.

We'll call them VLAN 10 and VLAN 20

On the Dell 6224 we can ping every item on the diagram from the
console.

On the VLAN 10 router, we were able to log into the web configuration
and ping from it to IP address set to VLAN 20 after we applied a
static route to the router from VLAN 10 to VLAN 20.

On the Dell 6224,  we have  been unable to set the static routes that
you can see below in the config. It reports no errors however the
route does not appear in the list when typing the command "Show IP
route static."  We do see a "connected" route.

On the VLAN 10 computer, we have been unable to ping the VLAN 20
computer which is the goal in this scenario. We have set a route on
the VLAN 10 router for 192.168.1.0 /24 with a router of 10.0.0.2.

We know we can do this in 5 minutes with a linux box. Perhaps there is
some trick to forwarding packets on the 6224?

Here is the .gif of the network diagram:
http://www.pccc.com/downloads/junk/junk/Mock%20Network.gif

Thanks ahead of time,

Nick

!Current Configuration:
!System Description "Dell PowerConnect"
!System Software Version 1.0.0.27
!
configure
vlan database
vlan 10,20
exit
stack
member 1 1
exit
ip address 192.168.2.1 255.255.255.0
ip https server
interface vlan 10
routing
ip address  10.0.0.2  255.255.255.0
exit
interface vlan 20
routing
ip address  192.168.1.6  255.255.255.0
exit

--More-- or (q)uit

ip routing
ip route 10.0.0.100 255.255.255.255 10.0.0.1
ip route 192.168.1.100 255.255.255.255 192.168.1.1
username "admin" password 05a671c66aefea124cc08b76ea6d30bb level 15
encrypted
ip ssh server
!
interface ethernet 1/g1
switchport access vlan 10
exit
!
interface ethernet 1/g2
switchport access vlan 10
exit
!
interface ethernet 1/g13
switchport access vlan 20
exit
!
interface ethernet 1/g14
switchport access vlan 20
exit

--More-- or (q)uit

exit

console#


VLAN Routing


I posted awhile back on another group explaining my situation. We are
trying to bring together two very large networks. So here is the
situation.

I have a church I'm trying to help out with a network topology.  They
have a school and a rectory they want to connect via fiber.

However, the school wants to continue with their outbound internet
connection and DHCP server.  The rectory also wants to continue with
their outbound internet connection and DHCP server.

Consolidation is NOT a possibility.

I'll attach the router config log and a simple diagram of our current
setup. But we've decided that we will create 2 VLANs and setup routes
between the two internally, on a single Dell Powerconnect 6224 that is
supposed to have Layer 3 routing capability.

So before deploying this. We've setup a mock network within our office
consisting of 2 Linksys WRT54G routers, 2 computers and 1 Dell
Powerconnect 6224 switch. We have setup 2 VLANs and placed 1 PC and 1
router in each VLAN and are attempting to allow the PCs to communicate
via routing through each VLAN.

We'll call them VLAN 10 and VLAN 20

On the Dell 6224 we can ping every item on the diagram from the
console.

On the VLAN 10 router, we were able to log into the web configuration
and ping from it to IP address set to VLAN 20 after we applied a
static route to the router from VLAN 10 to VLAN 20.

On the Dell 6224,  we have  been unable to set the static routes that
you can see below in the config. It reports no errors however the
route does not appear in the list when typing the command "Show IP
route static."  We do see a "connected" route.

On the VLAN 10 computer, we have been unable to ping the VLAN 20
computer which is the goal in this scenario. We have set a route on
the VLAN 10 router for 192.168.1.0 /24 with a router of 10.0.0.2.

We know we can do this in 5 minutes with a linux box. Perhaps there is
some trick to forwarding packets on the 6224?

Here is the .gif of the network diagram:
http://www.pccc.com/downloads/junk/junk/Mock%20Network.gif

Thanks ahead of time,

Nick

!Current Configuration:
!System Description "Dell PowerConnect"
!System Software Version 1.0.0.27
!
configure
vlan database
vlan 10,20
exit
stack
member 1 1
exit
ip address 192.168.2.1 255.255.255.0
ip https server
interface vlan 10
routing
ip address  10.0.0.2  255.255.255.0
exit
interface vlan 20
routing
ip address  192.168.1.6  255.255.255.0
exit

--More-- or (q)uit

ip routing
ip route 10.0.0.100 255.255.255.255 10.0.0.1
ip route 192.168.1.100 255.255.255.255 192.168.1.1
username "admin" password 05a671c66aefea124cc08b76ea6d30bb level 15
encrypted
ip ssh server
!
interface ethernet 1/g1
switchport access vlan 10
exit
!
interface ethernet 1/g2
switchport access vlan 10
exit
!
interface ethernet 1/g13
switchport access vlan 20
exit
!
interface ethernet 1/g14
switchport access vlan 20
exit

--More-- or (q)uit

exit

console#


Re: VLAN Routing


On Jun 21, 3:32 pm, Bowman.Nichol...@gmail.com wrote:

Quoted text here. Click to load it

The Dell will create ARP entries for these, since
these subnets are local, so that's why you won't see
these routes.  I bet you'll see ARP entries for these
if you do a "show arp".  Connected routes (and ARPs)
have a higher precedence than static routes.

Quoted text here. Click to load it

You need to do the same thing that you did on the VLAN 20
router that you did on the VLAN 10 router.  You need to
add a static route for the VLAN 10 subnet that points to the
Dell.  That is because the default gateway on the host in the
VLAN 20 network will be pointing to the VLAN 20 router
which won't know how to forward to the VLAN 10 subnet
unless you add a route for it.

Anoop


Re: VLAN Routing


Bowman.NicholasW@gmail.com wrote:
Quoted text here. Click to load it

"Very large" networks would usually be thousands, or tens of
thousands of hosts...

Quoted text here. Click to load it


Keeping things separate is usually best.  You might setup the routing
such that each net has a secondary (higher metric) route out though
the other.   It might even do that automatically if you use RIP.

Quoted text here. Click to load it





It might be best to use RIP and turn on dynamic routing on the hosts.

The routing tables on the hosts, the PCs and WRT54Gs need to have
an entry pointing to the Dell for each net, or else the WRT54G
needs to forward data to the Dell.

For the WRT54G this is in the Setup/Advanced Routing tab.

Set Operating mode to Router instead of Gateway.
The allows you to turn on RIP (most likely only for LAN/Wireless).
Also turn RIP on for the Dell, in which case it should start sending
out RIP packets telling other routers (and hosts with RIP enabled)
where it can route to and how direct the route is (how many hops).

Quoted text here. Click to load it

I don't know the Dell 6224 at all, but the commands don't
look right.  It would be usual for a router to automatically
include routes between its own ports.  You need static routes
to reach other routers.  The problem is that the WRT54G doesn't
know about the Dell, and it is the default route for the PCs.

Another way is to put a static route on each of the PCs pointing
to the Dell as a route to the other net.  For W2000 something like:

route -p add 10.0.0.0 mask 255.255.255.0 192.168.1.6 metric 1

and

route -p add 192.168.1.0 mask 255.255.255.0 10.0.0.2 metric 1

on the appropriate machines.

Otherwise, if you turn RIP on on the WRT54Gs, Dell, and the
hosts, they will pick up dynamic routes to the appropriate routers.

If you have more questions, comp.protocols.tcp-ip is better for
routing questions.

-- glen
