Hi,
We use a pfsense
formatting link
firewall.
Now say that I have three lan nics (in addition to wan) in this box. Nic1 at 192.168.10.1, Nic2 at 192.168.15.1 and Nic3 at 192.168.20.1, both Nic1 and Nic3 with default rules as of wan access (Internet works ok)..
In addition, any traffic from either Nic1 or Nic3 to subnet
192.168.30.0/24 should be routed via Nic2. Nic2 is connected to another router with ip 192.168.15.254. (Another port on that other router is connected to the 192.168.30.0/24 subnet which Ni1 and Nic3 need to communicate with).Do I use static routes or nat in this case? Traffic to the
192.168.30.0/24 subnet from workstations connected to Nic1 and Nic3 should be routed via 192.168.20.254 to find the 192.168.30.0/24 net.pfsense's static routes form contains the following fields: Interface destination network subnet mask gateway
Thanks a lot if someone can help me put in the right route here
Geir
