Non-PCI gigabit Ethernet controller

Hello there,

I wonder whether somebody provide non-PCI gigabit Ethernet controller. I mean a Ethernet transceiver with PHY and MAC that can interface a DSP, or a microcontroller to Ethernet communication. It seems most gigabit Ethernet controller are communicating to PCI bus. Thanks for the help,

DS

Reply to
DigitalSignal
Loading thread data ...

Any S-100 bus? ;-)

Reply to
James Knott

Hi,

I´ve been looking for a while and I´ve found several non-PCI gigabit controller. I give you a couple of them:

formatting link
--> L8104 : This one has it own interface
formatting link
--> 82547EI : It needs an Intel bus (CSA), so I don´t know if it´s useful for you. www.pmc-sierra --> S/UNI 1xGE Ethernet Controller
formatting link
(I don´t know the P/N of this one, but there are some)

I hope you find it useful!!

------------------------------------- DigitalSignal wrote:

##-----------------------------------------------##

Delivered via

formatting link
formatting link
no-spam access to your favorite newsgroup -

comp.dcom.lans.ethernet - 1780 messages and counting!

##-----------------------------------------------##

Reply to
gnathita

Hi,

ASIX Electronics Corporation will have a Non-PCI gigabit controller ready soon. The product part number is AX88180 LF, 128-pin LQFP, S-RAM like bus, GMII interace supported. ASIX website is

formatting link

------------------------------------- gnathita wrote:

##-----------------------------------------------##

Article posted with Cabling-Design.com Newsgroup Archive

formatting link
no-spam read and post WWW interface to your favorite newsgroup -

comp.dcom.lans.ethernet - 3074 messages and counting!

##-----------------------------------------------##

Reply to
Frank Fan

Thanks. It is helpful

DS

Reply to
DigitalSignal
