quick config for 2610 t-1 router to netgear firewall?|
|
|
Bookmark this page:
 Yahoo!
 Google
 Windows Live
 del.icio.us
 digg
 Netscape
|
|
|||||||||||||
|
Posted by brandon.vogel@gmail.com on February 6, 2009, 4:28 pm
Please log in for more thread options
T-1 (built in CSU in 2610) out the ethernet port into the netgear firewall router's 'Internet' port, and vice versa. I'm going to be doing multi NAT (most machines on one IP, some others have their own) on the Netgear, and just need the Cisco to simply push all traffic from Internet to / from the Netgear. Easy, right? Trying to figure out the right IP scheme / router config. Any ideas? | |||||||||||||
|
Posted by Doug McIntyre on February 6, 2009, 5:40 pm
Please log in for more thread options The cisco routes by default, which means you would either have to have real IPs on the LAN side beyond the WAN side (ie. your service provider routes you down another /30 for the cisco and netgear to talk), or you can NAT everything behind the cisco, and then NAT again on the Netgear, or you can bridge the data from interface to interface on the Cisco. (ie. with IRB). (kind of an odd link, but still works http://www.cisco.com/en/US/docs/optical/15000r4_0/ethernet/454/guide/irb.pdf | |||||||||||||
|
Posted by brandon.vogel@gmail.com on February 6, 2009, 8:39 pm
Please log in for more thread options > >Trying to figure out the right config to route all data coming from my
> >T-1 (built in CSU in 2610) out the ethernet port into the netgear > >firewall router's 'Internet' port, and vice versa. =A0I'm going to be > >doing multi NAT (most machines on one IP, some others have their own) > >on the Netgear, and just need the Cisco to simply push all traffic > >from Internet to / from the Netgear. =A0Easy, right? =A0Trying to figure > >out the right IP scheme / router config. =A0Any ideas? >
gear,
> The cisco routes by default, which means you would either have to have > real IPs on the LAN side beyond the WAN side (ie. your service > provider routes you down another /30 for the cisco and netgear to talk), > or you can NAT everything behind the cisco, and then NAT again on the Net= > or you can bridge the data from interface to interface on the Cisco.
cal/15000r4_0/ethernet/454/guide/...
> (ie. with IRB). > > (kind of an odd link, but still workshttp://www.cisco.com/en/US/docs/opti= Bridging sounds like what I would want to do, I just can't picture out the IP config mentally. I currently have the Cisco router set up with the firewall IOS, and am xfering the firewalling and NATting to the netgear. At this point, it might be easier to just skip the Netgear and do all my firewalling on the IOS firewall? | |||||||||||||
