Fairly new to CISCO PIX so forgive me if I'm asking the obvious...

I have a PIX that i want to configure to allow pinging of the inside PIX
interface from a host located on the PIX outside interface....

My config allows icmp any from the entire subnet on the outside interface to
the entire subnet on the inside interface - since the inside subnet covers
the inside interface I'd have thought this would have worked, but it doesnt.

I can ping any host on the inside interface subnet from the outside host,
but not the actual inside interface itself.....

In the log I'm getting:-

PIX-3-305005: No translation group found for icmp src
outside:192.168.100.100 dst inside: 192.168.1.1 (type 8, code0)

192.168.100.100 is the outside host, connecting via the PIX outside
interface 192.168.100.1, 192.168.1.1 is the inside PIX interface.

Any help greatly appreciated.




Re: PIX - enabling PING of inside PIX interface from a host on the outside....
You dont have a static command in place to allow the translation
from the outside network to the inside network.

Make the static translation and your good to go.

SuperDuperNetworkGOD

----------------------------------------------
Posted with NewsLeecher v2.3 Final
 * Binary Usenet Leeching Made Easy
 * http://www.newsleecher.com/?usenet
----------------------------------------------



Re: PIX - enabling PING of inside PIX interface from a host on the outside....


If your using the pix to segment two LANs then you can use the ICMP =
command:

[no] icmp {permit | deny} ip_address net_mask [icmp_type] if_name=20

If your using this firewall on the internet perimeter you'll have to =
create a static NAT entry and then create a access-list to allow outside =
to inside connections:

access-list 10 permit any host aaa.bbb.ccc.ddd eq echo-reply

aaa.bbb.ccc.ddd equals the ip address of your inside interface.




Quoted text here. Click to load it
