X-10 DS10A Door/Window Sensor

Have a question or want to start a discussion? Post it! No Registration Necessary.  Now with pictures!

Threaded View


I bought three of these sensors to use with X-10 home automation only
to find they only work with the security system.  Has anyone modified
these to work with Homeseer or MisterHouse and the RR501 receiver?  If
not, is there some documentation on the schematic, frequency and codes
these sensors use?

I want to use these detectors to automate a garage door, If I can these
would really simplify how this is done.

Thanks for the help and reply

Clay


Re: X-10 DS10A Door/Window Sensor


On Wed, 24 Aug 2005 09:06:32 -0700, commander_cad wrote:

Quoted text here. Click to load it

Dave Houston did create a PIC replacement for X10 MR26A, but unfortunatly
this is not available anymore. He could probably help you on the protocol.

He did sent me a PIC, and I did wrote a misterhouse module for it.
If you own a BX24-AHT, another great piece of hardware from Dave, you
should be able to receive the code as well, note that I never test
my misterhouse BX24-AHT module with the DS10A



Quoted text here. Click to load it
a garage door, If I can these
Quoted text here. Click to load it
--
----------------------------------------------------------------------
  Gaetan Lord - FTA - gaetan@sgi.com - SGI - Montreal, Canada
      "I deserve the right to be wrong"
----------------------------------------------------------------------


Re: X-10 DS10A Door/Window Sensor


Check out the W800RF receiver.
http://www.wgldesigns.com/w800.html
"The W800RF32 receives:
      All 256 house/unit code addresses
      All regular X10 RF commands (on, off, dim, brighten, etc.)
      Extended RF commands, such as those transmitted by X10's
Entertainment Anywhere remotes and X10 security modules such as the
DS10."


Quoted text here. Click to load it

Re: X-10 DS10A Door/Window Sensor


Yes, the W800 will work with those door/window contacts and HomeSeer
and I beleive MisterHouse.

Martin
www.AutomatedOutlet.com
